Fuses

202

L

Fuse number

Rating (Amps)

Fuse colour

Circuits protected

FA1

25

clear

Driver door controls

FA2

25

clear

Passenger door controls

FA3

25

clear

Rear left door controls

FA4

25

clear

Rear right door controls

FA5

-

-

-

FA6

15

blue

Rear accessory socket

FA7

30

green

Heated rear screen

FA8

-

-

-

FA9

15

blue

Trailer power

FA10

30

green

Driver electric seat

FA11

40

green

Trailer power

FA12

-

-

-

FB1

10

red

Park distance control

FB2

-

-

-

FB3

15

blue

Driver's seat heater

FB4

15

blue

Front passenger's seat

heater

FB5

15

blue

Caravan fridge

FB6

15

blue

Electronic centre differential

FB7

-

-

-

FB8

-

-

-

FB9

30

green

Passenger electric seat

FB10

-

-

-

FB11

-

-

-

FB12

-

-

-

FD1

10

red

Audio system and touch

screen

FD2

-

-

-

FD3

10

red

DAB

FD4

5

tan

Bluetooth telephone

FD5

-

-

-

FD6

10

red

Audio unit

203

Fuses

R

FD7

-

-

-

FD8

-

-

-

FD9

30

green

Audio amplifier

FD10

-

-

-

FD11

-

-

-

FD12

-

-

-

Fuse number

Rating (Amps)

Fuse colour

Circuits protected

Emergency equipment

204

L

Emergency equipment

HAZARD WARNING FLASHERS

If the vehicle is stationary in an unsafe location,
or may cause a hazard to other road users,
switch on the hazard warning flashers. Press
the switch to turn the hazard warning lamps
on.

Note: Hazard warning lamps can be used when
the ignition is on or off.

WARNING TRIANGLE

1. The warning triangle is located on the

left-hand side of the under-floor storage
area.

E80807

E83728

205

Status after a collision

R

Status after a collision

DRIVING AFTER A COLLISION

Before starting or driving

If the vehicle has been involved in an accident
it should be checked thoroughly before
attempting to start the engine or drive the
vehicle.

Check for :-
• Fuel leaks.
• Fluid leaks.
• Battery damage.
• Damage to wiring.
• Damage to lights.
• Damage to steering, suspension, wheels

or tyres.

• Sharp or protruding bodywork.
• Operation of doors and locks.
• Condition and operation of seat belts and

SRS components.

• Condition of child seats and their

mounting/attachment points.

Note: This list is not exhaustive.

Resetting the fuel cut-off

The fuel system cut-off forms part of the Safety
and Restraint System (SRS) fitted to your
vehicle. Following an impact, and depending on
the severity, the fuel pump may be switched
off.

1. Switch the ignition off, and wait for one

minute.

2. Turn the ignition on for 30 seconds.

3. Check the vehicle thoroughly for fuel leaks.

If a leak is detected switch the ignition off
immediately.
• The vehicle must not be started if a leak

is present. Seek qualified advice, and
have the vehicle recovered.

4. If no leaks are detected, start the vehicle.

When driving

When driving a vehicle which has been
involved in a collision use caution and pay extra
attention to the operation of the vehicle. If any
changes in vehicle operation after the collision
are noted when compared to it's operation
before the collision, do not continue to drive
the vehicle. Stop the vehicle as soon as it is
safe to do so, and have the vehicle recovered.

Pay particular attention to changes in :-
• Steering.
• Braking.
• Unusual noises.
• Warning lights or messages displayed.
• Problems with electrical systems.

WARNING

If the vehicle is involved in a collision it
should be checked by a Land Rover
Dealer/Authorised repairer, or suitably

qualified persons before starting or driving.

WARNING

The fuel cut-off should never be reset
if you can smell fuel, or a leak can be
seen. Doing so can lead to a fire which

may cause personal injury or death.
