Quick start

L

Wipers and washers

Windscreen wipers

1. Intermittent wipe/rain sensor

2. Low speed wipe

3. High speed wipe

4. Single wipe - pull down and release to

operate

5. Rotate control to adjust speed of

intermittent wipe or sensitivity of rain
sensor

Windscreen washer

Push the button on the end of the
lever to operate the windscreen
washer.

Rear wiper and washer

Pull the lever to position 6 for intermittent
operation of the rear wiper. Pull and hold the
lever in position 7 to operate the rear washer
and wiper.

Exterior lighting

Exterior lamps master switch

1. Exterior lamps off

2. Side lamps

3. Headlamps

4. Autolamps

• With the switch in AUTO and the engine

running or ignition on, a sensor
monitors the exterior light levels and will
automatically switch the side lamps and
dipped headlamps on and off as
required.

5. Headlamp levelling control (Halogen

headlamps)

6. Rear fog lamps

7. Front fog lamps

8. Facia illumination dimmer control

5

6

7

3

2

1

4

E83198

7

8

6

5

1

2

3

4

E83200

23

Quick start

R

Direction indicators and headlamp high
beam

Move the lever up or down to
activate the direction indicators.

Moving the lever up or down against

spring pressure and then releasing will flash
the indicators three times. Useful for lane
changing.

Push the lever away from you to
select headlamp high beam. A
warning indicator will illuminate on

the instrument pack.

To flash the headlamps, pull the lever towards
the steering wheel and then release.

Gearshift interlocks

Park

The remote control must be inserted in the
docking port, the footbrake applied and the
selector release button pressed before the gear
selector can be moved from P (Park).

Neutral

If the vehicle remains stationary with N
(Neutral) selected, the selector lever will lock
into the N position after 3 seconds.

Press the selector release button and apply the
footbrake to move the selector lever from N.

Automatic transmission

Sports mode

In Sports mode, automatic gear changing is
maintained but the gearshift changes are
modified to improve performance.

To select Sports mode, move the gear selector
from the D position towards the left-hand side
of the vehicle.

The word SPORT will appear on the instrument
pack display and the LED in the gear selector
surround will illuminate.

E83199

Operating note

If Terrain Response is fitted, Sports mode is
only available when the General program is
selected.

E83201

24

Quick start

L

CommandShift™

CommandShift gear selection can be used as
an alternative to automatic gear selection and
is particularly effective when rapid acceleration
or engine braking are required.

• Select Sports mode. The transmission will

automatically select the gear most
appropriate to the vehicle's road speed and
accelerator position.

• Moving the selector lever forward (+) or

backwards (-) and then releasing will
manually select a higher or lower gear
(when available). The message
TRANSMISSION COMMANDSHIFT
SELECTED will appear in the message
centre.

• Subsequent gear selections will display the

selected gear on the instrument pack
display.

• To deselect CommandShift mode, move

the selector lever back to the D position.

Cruise control

Cruise control enables the driver to maintain a
constant road speed without using the
accelerator pedal.

1. SET + : to set a road speed or increase the

speed in 2 km/h (1 mph) steps when cruise
control is operating.

2. SET - : to set a road speed or decrease the

speed in 2 km/h (1 mph) steps when cruise
control is operating.

3. RESUME: resumes the SET speed retained

in memory.

4. CANCEL: cancels cruise control but retains

the set speed in memory.

E83202

Operating note

Cruise control will automatically disengage
when the brake/clutch pedal is used or when
the vehicle speed falls below 30 km/h (18
mph).

1

2

3

4

E83203

25

Quick start

R

Hill Descent Control (HDC)

HDC operates in conjunction with the anti-lock
braking system to provide greater control in
off-road situations particularly when
descending severe gradients.

Press the switch (arrowed in
illustration) to select HDC. HDC can
be selected at speeds below 80

km/h (50 mph) but will not be fully active until
the vehicle speed reduces below 50 km/h (30
mph), confirmed by a continuously illuminated
HDC indicator in the instrument pack. Press the
switch again to deselect HDC.

Terrain Response system

The Terrain Response system, if fitted, is
always active and cannot be switched off.
When the vehicle is started the system will
normally start in the General program.

Manual selection of a special program, by
rotating the knob, will provide benefits in how
the vehicle can be driven over different
surfaces or terrains by automatically adjusting
the vehicle's drive and suspension systems.

It is recommended that a special program be
engaged whenever driving conditions could
become difficult, and cancelled once the
conditions for use are no longer present.

General

Suitable for surfaces that match
typical road surfaces.

 Grass-Gravel-Snow

Suitable for surfaces which are firm
but have a slippery surface, e.g.
grass, snow, loose gravel, pebbles,

or icy conditions. If the gravel is deep, the Sand
program may be more beneficial.

 Mud-Ruts

Suitable for soft, muddy, uneven or
deeply rutted ground.

E83204
