313

Telephone Introduction

R

VOICE ACTIVATION

(Where fitted)

The Bluetooth telephone system can be
used in conjunction with the voice
activation system to provide the driver
with completely hands-free
communication. Voice commands are
picked up by the system microphone.

For information about using voice
activation, refer to the Voice Control
section, starting on page 331.

!

WARNING:

The voice activation system must not
be used to call emergency numbers, as
voice patterns can change under
stress, resulting in commands
becoming unrecognisable.

SAFETY

!

WARNING:

Read this information before using
your in-car telephone system.

Driving

Check local regulations on the use of
telephones in the areas where you drive
and always obey them. Observe the
following guidelines when using your
phone whilst driving:
• Give full attention to driving - safe

driving is your first responsibility.

• Always use hands-free operation

when driving.

• When receiving a call, if driving

conditions demand, pull off the road
and park.

Electronic devices

Most modern electronic equipment is
shielded from radio Frequency (RF)
signals.

However, certain equipment may not be
shielded against RF signals from your
telephone.

Pacemakers

The Health Industry Manufacturers
Association recommends that a minimum
separation of 15 centimetres (6 inches) is
maintained between a wireless phone
antenna and a pacemaker to avoid
potential interference with the
pacemaker. These recommendations are
consistent with the independent research
by and recommendations of Wireless
Technology Research.

Telephone Introduction

314

L

Persons with pacemakers should:
• Preferably use the vehicle hands-free

system.

• ALWAYS keep the phone more than

15 centimetres (6 inches) from their
pacemaker when the phone is
switched ON.

• Turn the phone OFF immediately if

there is any reason to suspect that
interference is taking place.

Other medical devices

If you use any other personal medical
device, consult the manufacturer of your
device, or your doctor, to determine that it
is adequately shielded from external RF
energy.

Turn your phone OFF in health care
facilities when any regulations posted in
such areas instruct you to do so.
Hospitals or health care facilities may be
using equipment that could be sensitive
to external RF energy.

Vehicles

RF signals may affect non-Jaguar or
improperly installed equipment. Always
consult the manufacturer of any
equipment that has been retro-fitted to
your vehicle.

Posted facilities

Turn your phone OFF in any facility where
posted notices so require.

Blasting areas

To avoid interfering with blasting
operations, turn your phone OFF when in
a blasting area or in areas posted: Turn off
two-way radios. Obey all signs and
instructions.

Potentially explosive atmospheres

Areas with a potentially explosive
atmosphere are often, but not always,
clearly marked. Turn your phone OFF
when you are in such an area, as the use
of unapproved electrical equipment can
cause an explosion or fire resulting in
bodily injury or death.

Air bags

Air bags inflate with great force.

!

WARNING:

Do NOT place objects, including both
installed or portable wireless
equipment, in the area over an air bag
or in the air bag deployment area. If
in-vehicle wireless equipment is
improperly installed and the air bag
inflates, serious injury could result.

315

Telephone System

R

Telephone System

STEERING WHEEL CONTROLS

Four system control switches are situated
on the left-hand side of the steering
wheel, duplicating the functions of
buttons on the audio panel. These
switches provide finger-tip control of
audio, telephone and voice activation
systems whilst driving.

Note: Switches 2 and 4 are rocker
switches.

JAG0655

Switch

Function

1

Start voice function, or mute
where voice not fitted.
Answer phone call when
ringing.
Send/End when in Phone
mode.

2

Increase/decrease volume.

3

Hold for two seconds to
select Phone Ready mode.
Press and release to cycle
through FM, AM, CD and CD
Changer.

4

In Phone mode, scroll through
stored numbers.
In Audio mode, scroll through
radio stations or CD tracks.
Press and hold to select next
strong radio station or next
CD.

Telephone System

316

L

PAIRING YOUR PHONE

Before use, your mobile phone must be
connected or paired with the vehicle’s
Bluetooth system.

Vehicles with touch-screen

Follow these steps to pair your phone
with the vehicle:
• Switch the vehicle’s ignition ON

(position II).

• Press the

 button, to the left of the

touch-screen.

• Ensure that no phone is currently

connected to the car.

• The message Discover Me will be

displayed, to confirm that the system
is ready to pair with a mobile phone.

• Switch on your mobile phone’s

Bluetooth connection, using the
phone’s menu. (See your phone’s
manual for more information).

• Select search for other Bluetooth

devices or Audio Accessories from
your mobile phone’s menu.

• Select Jaguar in your phone’s paired

device list, in order to connect to the
vehicle’s Bluetooth system.

• Enter the Passkey on your mobile

phone (the Passkey is 1313).

• After a short delay, the messages

Registered followed by Phone
Connected will confirm that the
phone and vehicle are paired.

Note:

•

When a mobile phone is paired to the
vehicle and the Bluetooth connection
is established, at least one bar will be
displayed next to the antenna icon
(depending on the type of mobile
phone used and whether or not it
supports the Bluetooth signal strength
feature). However, you will need to
refer to your mobile phone’s display to
determine the strength of the network
signal.

•

If an incorrect Passkey is entered, your
mobile phone should prompt you to
enter the correct Passkey.
