197

Touch-screen Climate Control

R

TIMED AIR RECIRCULATION

Press the button briefly to select
air recirculation for a timed period
only; the pop-up shown above

will appear for a few seconds on top of the
currently selected touch-screen.

The fresh air intake is opened and the
button LED extinguished at the end of the
timed period.

Latched fresh air

Pressing the air recirculation button when
the button LED is illuminated will cancel
recirculation and allow fresh air into the
vehicle.

Deselecting air recirculation cancels
AUTO mode.

LATCHED AIR
RECIRCULATION

To latch air recirculation (so that it
remains selected), press and hold
the air recirculation button until

the pop-up changes from the timed to the
latched recirculation symbol.

Selection is also indicated by two beeps
and the button LED flashing four times
then remaining illuminated.

Selecting latched recirculation cancels
AUTO mode.

Caution: Prolonged operation with
recirculation selected in cold, damp
conditions could result in interior
condensation.

Touch-screen Climate Control

198

L

WINDSHIELD
DEFROST/DEMIST

Frost and heavy misting

To remove frost or heavy misting
from the windshield, press the
DEF button.

• The blower switches on automatically

at a high speed but the speed can be
increased or decreased manually if
required.

• Air conditioning switches on

automatically and cannot be
deselected.

• Recirculation is cancelled and cannot

be selected.

• The front screen heater and the rear

screen heater/door mirror heaters
switch on automatically, provided the
engine is running.

To deselect defrost mode, press DEF
again, or press AUTO (recommended
operating mode).

Light misting

To prevent or remove light
windshield misting, select
manual air distribution to

windshield and feet (see MANUAL AIR
DISTRIBUTION, page 199).

HEATED SCREENS AND DOOR
MIRRORS

The front screen heater (F) and
the rear screen heater (R) may be
switched on and off in any mode,
including system off, but only
operate when the engine is

running. The door mirror heaters are also
controlled by the rear screen heater
button.

The front screen heater (where fitted)
switches off automatically after
four minutes. The rear screen and door
mirror heaters switch off automatically
after ten minutes.

The windshield heaters may be manually
deselected during the time-out period
using the buttons.

In cold ambient conditions, at the start of
a journey, the front and rear screen
heaters will switch on automatically for
the timed period.

Where a front screen heater is not fitted,
the windshield has a wiper park zone
heater which operates automatically with
no manual control.

Note: The top three lines of the rear
screen pattern are a concealed antenna
and do not defrost the rear screen.

199

Touch-screen Climate Control

R

AIR CONDITIONING

Touch the A/C button to
switch the air conditioning on
or off.

The air conditioning system is controlled
automatically in AUTO mode. Deselecting
A/C cancels AUTO mode.

The air conditioning system is also
switched on automatically in defrost
mode (DEF) but cannot be deselected.

BLOWER SPEED

Set the blower speed as required
using the rocker button. Blower
speed is shown as a series of bars
on the touch-screen.

If the blower speed is changed while a
non-climate control touch-screen is
displayed, a pop-up display showing the
blower speed bars will appear for a short
period.

When operating in AUTO mode, blower
speed is controlled automatically (but not
displayed) and any adjustment of the
button will cancel AUTO mode.

Note: In AUTO mode, the blower will only
operate at low speed until the engine is
warm, if heating is required in the vehicle.

BLOWER MUTE

To reduce the interior noise
level, the blower speed may
be quickly reduced to a preset
level by touching the Mute
button.

Selecting Mute will cancel AUTO mode,
but touching the Mute button again will
return operation to the previous state.

When JaguarVoice is fitted, the climate
control system will automatically prevent
any increase in blower speed while
speech commands are given.

Note: The Mute function should only be
used for short periods, as it reduces the
efficiency of the climate control system.

MANUAL AIR DISTRIBUTION

Air distribution is automatically controlled
in AUTO and defrost modes.

Touch one of the four air distribution
buttons on the screen to cancel the
current mode and select manual
operation.

The air distribution options are:

Airflow directed at face
level only; select to cool
the interior.
Airflow distributed to the
face and feet.
Airflow directed to feet
level; select to heat the
interior.
Airflow distributed to the
windshield and feet; select
to prevent or remove light
misting and when heating
the interior.

Touch-screen Climate Control

200

L

SWITCHING CLIMATE
CONTROL OFF

To switch the system off,
touch the system ON/OFF
button on the climate control

screen. The touch-screen will change to
the system off/ram air climate control
screen above.

Pressing the system On/Off button will
return the system to the previous state.

It is recommended that AUTO is selected
to switch the system on again.

RAM AIR

With the climate control system switched
off, air recirculation is automatically
selected (intake flap closed).

To select fresh air with the system off,
touch the ram air button (bottom left on
illustration). The intake flap will open with
air distribution to face level automatically
selected.

Any of the other air distribution modes
may be selected manually using the
touch-screen.

With the blower switched off, the fresh
airflow results from the forward motion of
the vehicle (ram air mode).
