295

Satellite radio

If a valid channel has been entered, then
the following screen (Sat Radio Home
screen) will be displayed, but with the
new channel information.

Parental lock

This option allows the user to lock any
given channel or channels to prevent
them from being accessed.

The locked channels will be skipped
when navigating through the channels
using the seek up or seek down buttons.

To set-up, select Sat Options on the
satellite radio screen.

Note: Parental Lock cannot be
performed while the vehicle is in motion.

Select Parental Lock on the Sat Options
screen, and a numerical keypad will be
displayed. Enter a PIN number.

Number entry is identical to that for Direct
Channel Selection, except that there
must be four digits e.g. 125 must be
entered as 0125 etc.

If the correct PIN is entered the following
screen is displayed which shows the
different Categories and All Channels.

Pop category has been selected.

After selecting Pop, the following screen
will be displayed:

Two channels are shown with the Lock
symbol.

There are three keys that the user can use
to lock or unlock channels.

AM/FM

Sat Radio

Octane

Wax

CNBC

Strobe

The Pulse

---

Todays Stock Report

Sat Options

SR1 Ch105 Bloomberg

News

Settings

Audio

12 : 34 pm

E94034

Audio

SR1

Ch021 Octane

Enter PIN

Category Lists

Direct Channel

Parental Lock

Channel Skip

Sat Information

12 : 26 pm

E94035

SR1 Ch021 Octane

Audio

All Channels

Pop

Rock

R&B / Urban

Dance

12 : 34 pm

E94036

SR1 Ch021 Octane

Audio

040 Wax

041 Sirius Hits

042 Slow Jamz

043 The Express

044 The Vault

Lock All

12 : 34 pm

Edit PIN

Unlock All

E94037

Satellite radio

296

The user can lock or unlock an individual
channel or lock them all within a
Category. To lock an individual channel,
just select the desired channel and select
Lock or Lock All depending on what is
displayed. The unlock procedure is the
same.

Edit Personal Identification
Number (PIN)

To edit the parental lock PIN, the user
must first enter the existing PIN.

If the system confirms that the entered
PIN is the correct one it will respond with
PIN Verified - Enter New PIN.

Enter the desired PIN (four digits).

This new PIN will then be stored and
over-write the previous one. A SAT
Information pop-up will indicate New PIN
Accepted.

Viewing a locked channel

When a locked channel is selected by
Channel Navigation, Direct Channel Entry
or Search by Category, it will not play and
will give the message Channel Locked
Enter PIN.

Enter the PIN via the keypad which will
subsequently be displayed.

If the correct PIN is entered, the channel
will play. However, the channel will play
only for the current driving cycle and will
again be locked the next time that the
vehicle is started and used.

If the PIN that is entered is incorrect, the
message Entry Invalid - Please try
again will be displayed.

Lost PIN information

If the user loses or forgets the PIN,
access may still be gained and a new PIN
entered, as follows.

Select Sat Options on the satellite radio
screen, to display the Options screen:

• Select Parental Lock1 on the Sat

Options screen, and hold for 10
seconds - then release.

• Select SAT Information2 and hold

for 10 seconds - then release.

• After a time-out period, the system

will display User PIN Has Been
Reset.

The PIN will have been reset to the
system default of 1111.

Go to Edit PIN and enter a new number.

Channel Skip

Channel Skip can be used to hide
channels from being selected when using
the seek up and seek down buttons -
the channels are actually skipped, not
hidden.

Audio

SR1

Ch021 Octane

Enter PIN

Category Lists

Direct Channel

Parental Lock

Channel Skip

Sat Information

12 : 26 pm

E94038

Audio

SR1

Ch172 Intimate

User PIN Has been Reset

AM/FM

Sat Radio

E94039

12 : 26 pm

297

Satellite radio

Select Sat Options on the satellite radio
screen, to display the Options screen:

Select Channel Skip1 on the Sat
Options screen and the Category List will
be displayed.

Select the Category in which to view the
channels e.g. Pop2.

When Pop has been selected the
channels within that category will be
displayed.

Individual channels within a category can
be Skipped by selecting a channel and
pressing Skip.

All channels within a category can be
Skipped by pressing Skip All or
unskipped by pressing Unskip All.

Hidden (skipped) channels are accessible
by Direct Channel Entry.

Note: If same channel is locked and
skipped, then when the channel is
unlocked it will become unskipped.

SAT Information

The SAT Information screen contains the
SIRIUS contact telephone number and
the satellite radio Identification Number.

Select Sat Options on the satellite radio
screen, to display the Options screen.

Select SAT Information on the Sat
Options screen. This information is
displayed automatically when the system
is asking the user to subscribe to SIRIUS.

SR1 Ch021 Octane

Audio

Category Lists

Direct Channel

Parental Lock

Channel Skip

SAT Information

All Channels

Pop

Rock

R&B / Urban

Dance

12 : 34 pm

E94040

SR1 Ch021 Octane

Audio

040 Wax

041 Sirius Hits

042 Slow Jamz

043 The Express

044 The Vault

Skip All

12 : 34 pm

Unskip All

E94041

SR1 Ch021 Octane

Audio

Category Lists

Direct Channel

Parental Lock

Channel Skip

SAT Information

12 : 34 pm

Sirius Satellite Radio Inc.

For Subscription Information Call:

888 - 539 - SIRIUS

Your SIRIUS ID: 012345678910

E94042

Satellite radio

298

SUBSCRIPTION

When Sat Radio has been selected, but
a subscription to the provider has not
been made, a message will appear,
showing the telephone number of the
provider.

Also shown is the SIRIUS ID that
identifies the receiver unit and is linked to
the VIN of the vehicle.

To subscribe, call the number indicated
and quote the SIRIUS ID, this would
normally be done by your Jaguar Dealer.

If SIRIUS has not yet been subscribed to,
the system will tune to the preview
channel - currently number 184. This
channel is accessible for a limited period
only, for approximately 90 days after
purchase of the vehicle.

The ignition system must be ON and the
vehicle must be outdoors in plain view of
the sky whilst authorisation takes place.
This authorisation/activation can take up
to 15 minutes.

Unsubscribed radio channels

If a channel is selected for which there is
no valid subscription, Unsubscribed
Channel is displayed.

Either subscribe to this selected channel
or select an alternative channel that has
already been subscribed to.

At the bottom of the screen Call SIRIUS
to Subscribe is displayed. Select the
right arrow button to display the
Subscription Details Pop-up screen.

Automatic updates of channels

Occasionally the system will be updated
automatically by SIRIUS.

Whilst updating, the audio will be muted.

When updating has been completed the
update screen details cancel.

After the automatic update procedure,
the following should be noted:

1. All locked channels will be unlocked.

2. All skipped channels will be

unskipped.

AM/FM

Sat Radio

SR1 Ch021 Octane

Audio

Sirius Satellite Radio Inc.

For Subscription Information Call:

888 - 539 - SIRIUS

Your SIRIUS ID: 012345678910

12 : 34 pm

E94011

AM/FM

Sat Radio

Octane

Wax

CNBC

Strobe

The Pulse

---

Call SIRIUS to Subscribe

Sat Options

SR1 Ch150 Disney

Unsubscribed Channel

Settings

Audio

12 : 34 pm

E94012

AM/FM

Sat Radio

Audio

Sirius Update

Please Wait

60%

12 : 34 pm

E94013
