Quick start

Operation of the paddles whilst in D will
temporarily select manual gear selection
mode. This will be automatically
cancelled after a short period of driving at
a steady speed, or can be cancelled by
holding the (+) paddle for approximately
one second.

Operation of the paddles in S will
permanently select manual gear
selection. Once selected, it will only be
cancelled if the gear selector is moved
into D.

• To shift down, briefly pull the

(-)paddle.

• To shift up, briefly pull the (+)paddle.

Parking assist

When R (Reverse) is selected, the
touch-screen displays a representation of
the vehicle, and indicates any obstruction
which is detected to the front or rear of
the vehicle.

If an obstruction is detected, a coloured
bar will be displayed showing its
approximate distance from the vehicle.
This will be accompanied by an audible
alert that increases frequency as the
object is approached.

The volume of the alert can be changed
via the Vehicle -Parking settings on the
touch-screen.

Parking assist is automatically cancelled
when D (Drive) is selected, and the
vehicle speed exceeds 15 km/h (9 mph).
When driving into a parking space, front
parking assist can be enabled by
pressing the switch on the overhead
console.

Parking assist care points

Sensors may activate when water, snow,
or ice, are detected on the surface of the
sensors. This is normal for such sensors,
and regular cleaning will maintain
performance.

E92032

Home

Audio

Climate

Phone

Navigation

Vehicle

Valet

12 : 26 pm

Parking Aid Alert

E91478

Quick start

Parking assist may sound if it detects a
frequency range close to that of the
sensors (e.g. motorcycles, or air brakes).

Cruise (speed) control

Speed control is the standard cruise
control system which enables the vehicle
to maintain a set road speed until either
cruise control is cancelled, or the brake
pedal is applied.

The system is controlled via switches on
the steering wheel:

1. (+) or (-) to set the road speed to be

maintained, or increase or decrease
the speed in 2 km/h (1 mph) steps
when cruise control is operating.

2. CANCEL - cancels cruise control, but

retains the set speed in the memory.

3. RESUME - to resume a set speed

retained in the memory.

Note: Cruise control will automatically
disengage when the brake pedal is
applied, or when the vehicle speed falls
below 30 km/h (18 mph).

Adaptive cruise control (ACC)

ACC is designed to aid the driver to
maintain a gap to the vehicle ahead, or to
maintain a set road speed if there is no
slower vehicle ahead.

The system is controlled via switches on
the steering wheel:

1. (+) or (-) to set the road speed to be

maintained, or increase or decrease
the speed in 2 km/h (1 mph) steps
when cruise control is operating.

2. GAP - increase or decrease the time

gap to the vehicle ahead.

3. CANCEL - cancels cruise control, but

retains the set speed in the memory.

4. RESUME - to resume a set speed

retained in the memory.

The gap to the vehicle ahead can be
changed to one of four pre-defined
intervals. The current setting will be
displayed in the message centre.

E91491

WARNING

Adaptive Cruise Control is not a
collision avoidance system.

E91495

Quick start

If a slower vehicle is
encountered or enters the
same lane as you, the road

speed will be adjusted to maintain the
currently selected time gap. The warning
indicator will illuminate to indicate that
the vehicle is in follow mode.

Note: The system will NOT detect:

Stationary, or slow moving vehicles below
10 km/h (6 mph).

Pedestrians or objects in the roadway.

Oncoming vehicles in the same lane.

Touch-screen

The touch-screen allows control of the
audio, climate, phone, and navigation
systems. The screen only requires a light
touch to operate functions. Excessive
pressure on the screen can result in
damage to the screen.

1. Touch-screen. When initially

activated, the touch-screen will
display the Home screen.

2. Touch-screen On/Off. Press to turn

the screen on. Press to put the
touch-screen into screen saver
mode, press again to turn off the
screen.

3. Home screen button. Press at any

time to return to the Home screen.

Most screens feature a return
icon in the bottom right-hand
corner. Touch this icon to

return to the previous screen.

Sound settings

General operation

Press the control knob to switch On/Off,
and rotate to adjust volume.

Press the SOURCE button repeatedly to
scroll through FM1, FM2, AM, and CD
options.

Home

Audio

Climate

Phone

Navigation

Vehicle

External

Left

Right

Valet

Radio
90.7

FM1

KALX

12 : 26 pm

E93446

E92056

Quick start

Steering wheel controls

1. Rotate up or down to increase or

decrease volume.

2. Rotate up or down to scroll through

preset radio stations or CD tracks.
Holding the wheel in the up or down
position for two seconds will seek
forward or backwards to the next
available signal.

3. Press repeatedly to scroll through

FM1, FM2, AM, and CD options.

4. Press to mute the audio unit. This

button is also used in phone mode.

Radio operation

From the Audio control screen, touch the
AM/FM tab to select radio. Subsequent
touches of this icon will scroll through the
available wavebands.

Storing stations

Touch Autostore to automatically store
the nine strongest signals.

To manually store a station, search for
the station using the seek icons 1. Once
the station has been found, touch and
hold one of the station icons 2 to store the
station. An alert tone sounds to indicate
that the station has been stored.

The audio system has additional features
which include: FM text, Traffic
Announcements (TA), Programme Type
(PTY), Regionalisation (REG), and
Extended Other Networks (EON).

CD operation

From the Audio control screen, touch the
CD icon to access the CD player control
screen. The CD player has an integral
6-disc multi-changer. The example
illustrated shows the multi-changer
loaded with four CDs, with one disc
playing.

E91129

AM / FM

- -

Autostore

Settings

A u d i o

12 : 26 pm

PTY

3CH

770

WABC

WFAN

WXRP

WNYC

WPLJ

WQXR

WHTZ

WHUD

WCBS

E93447

Tr 15

03:25

D P L I I

Folders

Settings

A u d i o

AM / FM

Mix

Repeat

12 : 26 pm

E93448
