Exterior Lighting
R
Exterior Lighting
MASTER LIGHTING SWITCH
The exterior lamps are controlled by the
left-hand column lever switch.
The rotary collar on the lever has three
positions for turning the exterior lamps on
or off and positions for autolamps and exit
delay. These are:
OFF
All exterior lamps OFF (except vehicles
provided with daylight running lights).
Side lamps
Switches on front side lamps, tail, license
plate and any other marker lamps
required by local legislation. When the
external lamps are ON the instruments
will also be lit.
Headlamps
With the ignition in position II, this
position switches on low headlamps in
addition to the lamps switched on in side
lamp position.
The left-hand column lever switch has
two positions for controlling the high
beam.
Pulling the switch towards the steering
wheel and releasing causes the high
beam to flash on and off. The high beam
can be flashed at any time when the
switch is pulled and will remain ON for as
long as the switch is held.
The second position is to switch high
beam headlamps ON. With the ignition in
position II, first select low beam lamps,
and then push the column lamp switch
away from the steering wheel.
The blue warning lamp on the instrument
pack and high beam headlamps will come
ON.
To turn high beam OFF, pull the column
switch towards the steering wheel to
return to low beam.
Note: If low beam is switched OFF, with
high beam still activated both low and
high beam will be extinguished. Both low
and high beam will illuminate if low is
turned on again.
