JAC S1. Manual - part 7

Exterior rear view mirror
Electronic control

Exterior rear view mirrors are de鄄
signed to allow you observe rear po鄄
sition and the distance at left & right
side correctly.

Switch of remote controlled exterior
rear view mirrors can allow you to
adjust the positions of the rear mir鄄
rors left and right.
Adjusting the mirrors:
1援Move the control switch to left or
right to select relevant rear mirror.
2援Press the adjusting switch to get
the desired angle of rear mirror.

Day/night interior rear view
mirrors

Your vehicle is installed with day/

night rear view mirrors. When you
drive in night, pulling the day/night
link towards you can reduce the
strong light of headlight from behind
the vehicle.

Roof carrier

If your vehicle is equipped with roof
carrier, you can carry goods on the
roof. You can get some parts for in鄄
stalling roof carrier from authorized
JAC dealer.

Warning院

音 Do not fold mirror during vehicle
running. If you do not obey this,
out of control may occur and so
serious hurt even death will result.

Characteristics of JAC vehicle

Rear brake light

Low rear brake light is installed on
both sides of the vehicle, and high
brake light is installed in the middle
of the vehicle. When you step brake
pedal, these lights will illuminate.

Openthefillercapwithyourhand

Pull up the release rod (on the floor)
in the left front corner of driver seat
and open the filler cap.

Note院
音 If the cap can not be opened
because of icing, you can push
or tap it slightly. If necessary, in鄄
ject melting agent around the cap
(do not use radiator), or move the
vehicle to a warm place to make
the frozen cap melt.

Caution院
音 When you carry the goods,
please note the following.

音 Goods exceeding 34 kg can
damage your vehicle. When you
carry big goods, do no hang the
goods in rear position or outside
of the side face.
音 During running, to avoid
damage of or lost goods, please
check if the goods be secured.
音 Drive the vehicle as stable
speed.
音 The roof carrier can be used
as rear balustrade. You must fix
the roof carrier with two or more
cross bearers before carrying

roof carrier

34 kg

load evenly

goods.
音 After fixing the bearers, you
can carry goods over the roof
carrier.
音 Carrying too heavy goods
may damage your vehicle.

Warning院

音 Ensure that the support rod
has been released, and close
the engine cover. Before driving,
please confirm that the engine
cover is locked. If not, it will be

Therefore, this is a normal phe鄄
nomenon. Rotating the filler cap
slowly can open it.

Engine cover

1援Pulling the release rod can open
the engine cover.
2援Press and hold on the safety lock鄄
ing rod, and uplift engine cover.
Before closing the engine cover, the
support rod should return to its origi鄄
nal position; otherwise there will be

noise. Lower the engine cover to the
closing position that is higher than 30
cm, and lock it. Please confirm that
the engine cover is locked in correct
position.

Warning院

音 Gasifying of gasoline is very
important. When filling the fuel, the
engine should be stopped and no
spark shall be generated or igni鄄
tion performed near the filler cap.
If you need to replace filler cap,
please use genuine JAC parts of
good quality. If you open the filler
cap at high temperature, you can
hear a slight "squeak".

Characteristics of JAC vehicle

Sun visor

Sun visor is installed in the front and

side of driver seat & passenger seat.
In order to ward direct sunshine, you
can pull down the sun visor. Pocket
mirror is installed in the right side of
sun visor of front passenger seat.

Light of pocket mirror

音 After the light is on, open the
pocket mirror cover beside driver
seat or front passenger seat, then the
light of pocket mirror will illuminate
automatically.

Warning light at front door cor鄄
ner

After opening the front door, the red
light will illuminate. The aim of this light

opened during running, resulting
in blocking of sight and acci鄄
dent. Please check if the front
support rod of engine is in cor鄄
rect position, thus to avoid the
engine cover falling on your
body. Do not move the vehicle
when the engine cover is sup鄄
ported.

Note院
音 Operation manual of SRS can
be found on the back of each
sun visor.

Warning院

音 If the visibility of road is bad,
or in road subject to accident, or
there is obstacle in the road, do
not pull down the sun visors.
Pocket mirror

is to prompt access of passenger.

Horn

Pressing the steering wheel gasket,
you can hear the sound of the horn.

Armrest for rear seat

This armrest is in the center of rear
seat back.

Adjusting rod for steering wheel
tilting

Adjusting steering wheel
1援Pulling the adjusting rod forward
and holding it on can release steer鄄
ing wheel.
2援Raise or lower the steering wheel.
3援After adjustment, release the ad鄄
justing rod.

Warning院

音 Do not try to adjust the
steering wheel during running;
otherwise the vehicle will be out
of control and serious hurt even
death will be caused.

Characteristics of JAC vehicle

Automatic preheating and cooling control unit

Your vehicle is installed with automatic preheating and cooling control unit, by which you can set appropriate internal
temperature.

1援Air temperature control button
2援AUTO渊automatic control冤switch
3援Display panel
4援Closing switch
5援Fan blower control switch

6援Air conditioner switch
7援Air intake control switch/air flow system switch
8援Air flow control switch
9援Defrosting switch

Automatic operation

FATC

(full automatic temperature

control) system
It can control preheating and cooling
system automatically:院
Press "AUTO" switch. The indicator
will confirm auto control position
mode for face, feet, and face/feet
automatically. Except for blowing
speed, the air conditioner will oper鄄
ate automatically.

Interior temperature control
switch

Manual operation
Except for the "AUTO" button, you
can use the other buttons to control
preheating and cooling system man鄄
ually. At this time, you can control the
operation of the system by selecting
buttons in advance.
The buttons that can not be selected
are for automatic control.
Pressing "AUTO" button to change to
automatic mode.

Solar sensor

Note院
音 This sensor is installed on the
instrumental panel. Its function is
to determine that nothing is on
the sensor of the function of
preheating and cooling system.

Characteristics of JAC vehicle

Control switch for fan speed

Pressing control button for fan speed
can set the fan speed to appropriate
value. Faster speed can provide
higher air flow. Pressing "OFF" button
can close the fan.

Closing preheating and cooling
system

Pressing "OFF" button can stop the
preheating and cooling system.

Air flow control switch

This switch can control air flow di鄄

rection. The air can flow to feet, pan鄄
el outlet or windshield position. Four
marks are indicating the position of
face, feet, face/feet, and feet -de鄄
frosting respectively.

Feet and face position

If you select "feet and face" mode,
the indicator will illuminate, and the
air will flow out from air holes of face
& feet. In addition, cold air from air
hole of instrument panel and warm
air from air hole of feet can flow out
at the same time.

Face position

If you select "face" mode, the indica鄄
tor will illuminate, and the air will flow
out from air hole of face.

Feet position

If you select "feet" mode, the indica鄄

tor will illuminate, and the air will flow
out from air hole of feet.

Feet-defrosting position

If you select "feet-defrosting" mode,
the indicator will illuminate, and the
air will flow out from air hole of wind鄄
shield defrosting & feet.

Defrosting switch

If you press "defrosting" button, "fresh"
mode will be automatically chosen, and
the air will flow out from windshield de鄄
frosting air hole. If the temperature in
the vehicle exceeds normal tempera鄄
ture of 33.5益, the air conditioner will run;
If less than 33.5益, the air conditioner will
stop running automatically.
