Air operated outrigger
3. Lift the engine cover to the highest
point (air operated outrigger support).
Electric window
The switch of electric window locates at
the door handle at the driver爷s side. In
addition, each passenger door is e鄄
quipped with their individual window
switch.
Press downward the switch and the
window glass can be lowered.
Lift upward the switch and the window
glass can be lifted.
Lower the window glass rapidly
The windows on the four doors can be
rapidly lowered if the switches are tem鄄
porarily pressed downward to the bot鄄
tom (around 50ms) and then loosened.
By doing this, the window glass can be
completely lowered.
When the window glass is declining,
you can stop its moving by press the
switch once again. You can also lift the
glass by lifting the switch and hold it for
a moment.
Friendly Tips
淫 The electric window can be used
only when the ignition switch is con鄄
nected.
淫 The rear window cannot be fully
lowered.
-11
MO TORS
Notes
When driving, do not press the above
button, for the oil tank cover will be
opened if this button is pressed.
Oil tank cover release button
Press the oil tank cover switch on the
left switch group assembly of instrument
desk, and you can open the oil tank
cover.
Engine hatch cover
1. Pull the engine cover release bar at
left lower side of console.
2. Extend your hands to the front lower
side of the engine cover and turn the
engine cover release bar leftward.
-10
