Acoustic apparatus
on/off
Press

for start, and press

over 2 seconds and the master unit is turned off.

Sound volume
Press - or + to adjust the volume.
Mute
Short press

key to enable/disable mute mode.

Sound effect mode
Select the desired type of sound effect as per your personal preference. Press SOUND key to select BASS-TRE, and
press the sound volume key +/- to adjust the type of sound effect.
RND*噎噎CD random play on/off
RPT*噎噎CD repeat on/off
SCN*噎CD music scanning

原BA S -TRE院 auto setting the

BASS or TREoftheapparatus.

原FLAT院Original

原JASS院Jazz music
原VOCAL院Speech
原POP院pop music
原CLSSSIC院classical music
原ROCK院rock & roll music

OWNER爷S MANUAL

JAC High end Light Trucks

Acoustic mode setting
Press SOUND key to select the item you want to adjust.
Again press +/- key to adjust the item selected.
Five seconds later the screen turns back to the previous mode.
Only with BASS-TRE selected as the sound effect mode, can BASS and TRE
settings be adjusted.

Sound source selection
Press SOURCE key to select the desired sound source.
When a cassette is inserted in, the sound source will be automatically changed from radio to cassette play. Please take
out cassette when you want to listen to radio, so as to protect the unit.
Radio
Wave band
Press the BAND key to select the wave band desired.

原Sound effect type院渊BAS-TRE袁FLAT袁

JASS袁VOCAL袁POP袁CLSSSIC袁ROCK冤
原BASS院deep sounding

原TREBLE院high pitch

原BLANCE院balance on left and right

原Radio
原CD/Cassette*

Auto search
Press Button

to auto search the radio stations.

Press

key tune to the radio stations of low frequency, or press key

to tune to the radio stations of high fre鄄

quency.
You may press the same key if you want to search for another radio station.
Manual search (if you know the frequency of the radio station you need)
Long press Key or

for about 2 seconds before entry of manual search. Press Key for search of low-frequency ra鄄

dio stations.
Press for search of high frequency radio stations (If there is no search in 5 seconds, the system will return to the previ鄄
ous operation state).
Preselected radio stations (stored or preselected)
Manual storage of radio stations in preset keys
Use the preset keys (1-6) to store 6 radio stations in each wave band. Tune to the radio station desired, and press the
preset key needed (1-6) for 2 seconds at least, and the radio station available now can be stored into this preset key.
Call back the presetting
Press the preset key needed (1-6), the preset radio station will be called out.
Auto storage of radio stations
This function can auto store 6 FM radio stations(with most powerful signals) in the FMAST wave band or 6 MW(AM) radio
stations

OWNER爷S MANUAL

JAC High end Light Trucks

(With most powerful signals) in the MW (AM) wave band. When this auto storage function is used for new radio stations,
new radio stations will take the place of those stored previously in FMST or MW (AM)AST waveband.
Press AST key to activate the auto storage function.
The main unit gives out "beep" before muteness.
"Beep" can be heard after the storage is over.
Sometimes less than 6 radio stations can be found.
CD play *(CD)
Put the disc (printed side up)into the disc chamber and the play begins.
If a disc is already in the chamber, press the SOURCE key to select CD as the source. Play begins.
Previous/next music
Press Key 3 or 4 to select the music desired. Play begins with the music selected.
Music fast forward/backward
Press Key 3 for more than 2 seconds to drive the disc fast forward or fast backward. Release the key and the normal play
will go on.
Random play
Press RND key for at least 2 seconds to activate/quit Random play.
Repeated play
Repeat the play of the present music. Press RPT key for at least 2 seconds to activate/quit the Repeated play.
Music scan
This function can scan each of the music pieces for several seconds. Press the SCN key to activate/quit the Music scan

function.
Disc eject (CD)
Press the 银 key to eject the disc.
Change over the display mode(CD)
Press FUNC key to select the DIS menu.
Press the DIS key and you may have display changeover among the music number/played time, total music time/total
music numbers, sound effect mode and clock mode.
Display mode changeover(multi-disc CD)
Press FUNC key to select the DIS menu.
Press the DIS key and you may have display changeover among the music number/played time, total music time/total
music numbers, sound effect mode and clock mode.
Troubleshooting
If you find some of the functions of the acoustic apparatus in your vehicle do not work any more, you'd better do a careful
reading of the instructions in the manual before having it repaired, and do a check against the list below. And this will be
helpful to you in troubleshooting. If the trouble cannot be removed still, please send it to the maintenance station for re鄄
pair. Do not dismantle and repair it by yourself.

OWNER爷S MANUAL

JAC High end Light Trucks

Before driving

Proper maintenance and driving can prolong the vehicle service life, but also improve the economy of fu鄄
el consumption. Please drive your vehicle carefully.

Operation of controllers
Key
This key is used to operate the startup switch and door lock. Each key is
carved with a number, and kept in a safe place. Do not leave it in the vehicle.

Outer door-handle
Pull outward the outer door-handle and the door is opened.
Insert the startup switch key into the door lock and take a turn, the door can be
locked.

OWNER爷S MANUAL

JAC High end Light Trucks

Door lock (outside)
The vehicle doors can be locked, from outside without the key, by pressing the
lock pin (on the inside of the door) in "LOCK" position, and pull outward the
outer door-handle, and the door is locked.

Inner door-handle
Pull out the inner door-handle and the door is opened.
