Use of instruments and ap鄄
paratus in the cab
Integrated switch and instru鄄
ment cluster
Integrated switch
(figure below),
which is composed of steering shaft
lock seat尧ignition start lock and
combination switch lies underneath
the steering wheel.
Ignition switch
Ignition switch is on the right side of
integrated switch. It has four func鄄
tions: LOCK尧ACC尧ON尧START. When
the key is on the 'LOCK' position,
the ignition switch has been connect鄄
ed to the power source and lockup
of the steering gear has been disen鄄
gaged. Turn the key to 'ACC' posi鄄
tion clockwise, and circuit of acces鄄
sories like radio and tape player is
connected. Turn the key to "ON' po鄄
sition, and the instrument circuit is
connected. If keep on turning the key
to 'START' position, engine can be
started. You should unlash handle of
the key immediately after the engine
starts. The key can return to "ON'
position by the action of spring.
Combination switch (left control han鄄
dle)
Combination switch is under the
control of the multifunctional handle,
which lies in the lower left and inferi鄄
or place of the steering wheel. It can
control small light尧headlight尧head鄄
light dimmer and left turning or right
turning by two different motion
modes. The symbols and functions of
integrated switch
Ignition switch
2
Ignition switch
Integrated switch
OWNER爷S MANUAL for
HFC1061,HFC1063,HFC1083
series trucks
the combination switch are as fol鄄
lows:
荫
"OFF" indicates that neither small
light nor headlight lights.
荫
is the indication of small
light. Turn the control handle clock鄄
wise by 30o to lighten the front尧rear
small lights and the instrument light .
荫
is the indication of head鄄
light. Keep on turning the left control
handle clockwise by 30oto lighten
the front headlight尧the rear small
light and the instrument light .
荫
is the indication of steering.
Forward and backward motion of the
control handle can operate the left
and the right turning lights and the
turning light indicator on the instru鄄
ment panel. Push the control handle
forward in horizontal direction, the
right turning light lights and there is
indication of turning right on the in鄄
strument panel. On the other hand,
pull the control handle backwards,
the left turning light lights and there
is indication of turning left on the in鄄
strument panel. If the control handle
is in the middle position, there will be
no indication of turning.
荫
Dimmer of headlight: Lift the left
control handle upwards gently and
do the "uplift-release" motion, which
can control the dimmer function of
the headlight. If uplifting the handle
once, high beam headlight lights; if
releasing the handle, it goes out. Re鄄
peating of the above action can con鄄
trol the working condition of the high
beam headlight to achieve the pur鄄
pose of dimmer function when over鄄
taking at night.
Combination switch (right control
handle)
荫
is the indication of syringe.
When the washer control button on
the top of the control handle is
pressed, cleaning mixture (antifreeze
should be used in winter) in the win鄄
dow washer which lies in the right
doorframe and underneath instru鄄
right control handle
left control handle
