Iveco EuroCargo (12 to 26 t). Manual - part 10
E
URO
C
ARGO
T
ECTOR
12-26 t
30
ENGINE F4 AE 0481
Base - February 2003
PART
TORQUE
Nm
kgm
Cylinder barrel lubrication nozzle fixing screw M8
15
± 3
1.5
± 0.3
Engine shaft cap fixing screw M12
1
st
phase
2
nd
phase
d
50
± 6
80
± 6
5
± 0.6
8
± 0.6
2
phase
3
rd
phase
90º
± 5º
Stud bolts M6 for camshaft sensors
8
± 2
0.8
± 0.2
Stud bolts M8 for power supply pump
12
± 2
1.2
± 0.2
Rear gearcase fixing screw M12
Rear gearcase fixing screw M10
Rear gearcase fixing screw M8
77
± 12
47
± 5
24
± 4
7.7
± 1.2
4.7
± 0.5
2.4
± 0.4
Camshaft sensor fixing nut M6
10
± 2
1
± 0.2
Oil pump fixing screw M8
1
st
phase
2
nd
phase
8
± 1
24
± 4
0.8
± 0.1
2.4
± 0.4
Front cover fixing screw M8
24
± 4
2.4
± 0.4
Screw M8 for camshaft longitudinal check plate fixing
24
± 4
2.4
± 0.4
Camshaft gear fixing screw M8
36
± 4
3.6
± 0.4
Connecting rod cap fixing screw M11
1
st
phase
d
60
± 5
6
± 0.5
Connecting rod cap fixing screw M11
1 phase
2
nd
phase
60º
± 5º
Underblock plate fixing screw M10
43
± 5
4.3
± 0.4
Nut M8 for high pressure pump gear fixing
105
± 5
10.5
± 0.5
Fuel pump fixing nuts M8
24
± 4
2,4
± 0,4
½ inch plug on the cylinder head
¼ inch plug on the cylinder head
¾ inch plug on the cylinder head
24
± 4
36
± 5
12
± 2
2.4
± 0.4
3.6
± 0.5
1.2
± 0.2
Injector fixing screws M6
8.5
± 0.35
0.35
± 0.035
Injector fixing screws M6
75º
± 5º
Union fixing nut for injector power supply
50
± 5
5
± 0.5
Pre-heating grid nut M6 on the suction manifold
8
± 2
0.8
± 0.2
Suction manifold fixing screw M8
24
± 4
2.4
± 0.4
Rear bracket fixing screw M12 for engine lifting
77
± 12
7.7
± 1.2
Common rail fixing M8 screws
24
± 4
2.4
± 0.4
High-pressure fuel pipe unions M14
20
± 2
2
± 0.2
Cylinder head fixing M12 screw (12x1.75x 130)
1
st
phase
}
35
± 5
3.5
± 0.5
Cylinder head fixing M12 screw (12x1.75x 150)
1
st
phase
}
55
± 5
5.5
± 0.5
2
nd
phase
90º
± 5º
3
rd
phase
90º
± 5º
Equalizer support fixing screw
36
± 5
3.6
± 0.5
Valve clearance adjustment nut
24
± 4
2.4
± 0.4
Power supply pipe fixing nuts M14 from common rail high pressure pump
20
± 2
2
± 0.2
High pressure pipe union fixing screw M8
24
± 4
2.4
± 0.4
Head bulkhead fixing screw M6 for harness
10
± 2
1
± 0.2
Electric harness support fixing screw M8 for injector power supply
24
± 4
2.4
± 0.4
Harness fixing nuts on individual injector
1.5
± 0.25
0.15
± 0.025
Fuel filter-holder bracket fixing screw M8
77
± 8
7.7
± 0.8
Fuel filter-holder fixing screw M8
24
± 4
2.4
± 0.4
Fuel filter
contact +
¾ turn
Oil pressure adjustment valve fixing screw M22 on the oil filter support
80
± 8
8
± 0.8
Oil filter support and gasket radiator fixing screw M8
24
± 4
2.4
± 0.4
Oil filter
contact +
¾ turn
