Iveco Stralis AT/AD. Manual - part 366
VI.2
BLOCK DIAGRAMS
S
TRALIS
AT/AD
Base - January 2003
Chart 20:
Central door lock
22
. . . . . . . . . . . . . . . . .
Chart 21:
Ecas (warning lights) -
ABS (warning lights)
23
. . . . . . . . . . . . . . .
Chart 22:
EBS (warning lights) -
Heated windscreen - PTO
24
. . . . . . . . . .
Chart 23:
Retarder (warning light) -
Cabin tilting
25
. . . . . . . . . . . . . . . . . . . . . .
Chart 24:
Brake air pressure - ECAS -
Outside temperature
26
. . . . . . . . . . . . . .
Chart 25:
Trip odometer / total odometer - speed
limiter
27
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Chart 26:
Engine oil temperature — Beacon
lights — Sun visor
28
. . . . . . . . . . . . . . . . . .
