Iveco Stralis AT/AD. Manual - part 251
S
TRALIS
AT/AD
62
AIR SYSTEM - BRAKES
Base - January 2003
PART
TORQUE
Nm
(kgm)
Added rear axle disc brakes 56082/I
Nut fixing wheels
665
± 61.5
(67.8
± 6.2)
Screw fixing drive shaft flange
• *
90
± 10
(9.2
± 1)
Ring nut fastening wheel hub bearing
932
± 98
(95
± 10)
Screw fixing brake disc to wheel hub
281.5
± 13.5
(28.7
± 1.3)
Nut for screw fixing brake calliper to mount
615.5
± 61.5
(62.7
± 6.2)
Nut for screw fixing brake calliper mount
289.5
± 14.5
(29.5
± 1.5)
• Apply LOCTITE 243 sealant onto the thread
*
Spread the drive shaft / wheel hub contact surface with sealant type IVECO 1905685 (LOCTITE 14780)
MS 13-175 rear axle disc brakes
Nut fixing wheels
665.5
± 61.5
(67.8
± 6.2)
Screw fixing drive shaft flange *
262
± 27
(26.7
± 2.7)
Ring nut fastening wheel hub
932
± 98
(95
± 10)
Screw fixing brake disc to wheel hub
281.5
± 13.5
(28.7
± 1.3)
Screw fixing brake calliper to mount
615.5
± 61.5
(62.7
± 6.2)
Nut for screw fixing brake calliper mount
289.5
± 14.5
(29.5
± 1.5)
*
Spread the flange / wheel hub contact surface with sealant type IVECO 1905685 (LOCTITE 14780)
MS 13-175 rear axle drum brakes
Nut fixing wheels
665.5
± 61.5
(67.8
± 6.2)
Screw fixing drum
54.5
± 12.5
(5.5
± 1.2)
Screw fixing drive shaft flange *
262
± 27
(26.7
± 2.7)
Ring nut fastening wheel hub
932
± 98
(95
± 10)
Nut for screw fixing brake mount
289
± 14.5
(29.5
± 1.5)
Screw fixing speed sensor mount
•
6
± 1
(0.6
± 0.1)
RT 160 E/1 rear axle drum brakes
Nut fixing wheel
600
+50
- 20
(61.2
)
+5
- 2
Screw fixing drive shaft flange *
232.4
± 24.5
(23.2
± 2.5)
Ring nut fastening wheel hub H
392.3
(40)
Nut for screw fixing brake mount
289
± 14.5
(29.5
± 1.5)
*
Spread the flange / wheel hub contact surface with sealant type IVECO 1905685 (LOCTITE 14780)
Added axle drum brakes 56082/1
Nut for screw securing brake mounting
290
± 14.5
(29
± 1.5)
Tapered threaded plug for wheel hub cover
27
± 2
(2.7
± 2)
Ring nut for wheel hub bearings *
392.3
(40)
*
See adjustment on rear axle section.
