4
SUSPENSIONS
S
TRALIS
AT/AD
Base - January 2003
mm
8 tonnes parabolic leaf springs
No. 2
L
Spring length
(measured at eye centres)
1900
+ 0
- 6
S
Leaf thickness (measured at centre)
- master leaf
- 2
nd
- 3
rd
leaf
25
26
S
Distance between leaves
3
L
Leaf width
90
D
Inside diameter of master leaf eye
(bushing seat)
60.1
÷ 60.2
D
d
D = outside diameter of bushing
d = inside diameter of bushing
62.0
÷ 62.8
20.2
÷ 20.5
NEW LEAF SPRING CHECK DATA
Flexibility mm/KN
4.41
