Iveco Daily. Manual - part 377

72

ELECTRIC/ELECTRONIC SYSTEM

D

AILY

Base - May 2004

Cable

colour code

Function

72042A

1

0000

Earth

72042A

2

3330

Front clearance light

Connection between cab roof lamp and left front clearance light cable

72042A

3330

0000

0000

3330

Figure 72

8616

8587

8617

ELECTRIC/ELECTRONIC SYSTEM

73

D

AILY

Ref.

Cable

colour code

Function

72042B

1

0000

Earth

72042B

2

3330

Front clearance light

Connection between cab roof lamp and right front clearance light cable

72042B

3339

0000

0000

3339

Figure 73

8587

8616

8617

74

ELECTRIC/ELECTRONIC SYSTEM

D

AILY

Base - May 2004

Cable

colour code

Function

72043

1

0000

Earth

72043

2

2228

Fog lamps

Connection between cab/bonnet cable and fog lamp cable

72043

2228

0000

0000

2228

Figure 74

8587

8618

8619

ELECTRIC/ELECTRONIC SYSTEM

75

D

AILY

Ref.

Cable

colour code

Function

1

0003

Switching on roof lamp

2

4418

Supply (+30)

72046 3

0000

Earth

72046

4

1125

Positive with direction indicators/hazard warning lights on

5

1172

Additional stop light

6

0000

Earth

Connection between right tail light cable and rear roof lamp cable

72046

1172

0000

1125

4418

0003

0000

4418

0003

0000

1172

0000

Figure 75

8587

8590

8591
