Figure 2

SECTIONAL VIEW OF 450310 REAR AXLE DIFFERENTIAL

101961

REAR AXLES 450310

AILY

Revi - February 2005

COMPONENT

TORQUE

kgm

Bevel pinion retaining nut

400

÷ 500

÷ 50

Screw securing gear housing to ring bevel gear

÷ 108

8.9

÷ 10.8

3**

Oil filler plug

÷ 62

4.9

÷ 6.2

Screw securing caps to differential housing

100

÷ 120

÷ 12

Screw securing gearing inspection cover to the axle housing

÷ 95

÷ 9.5

Screw securing gearing inspection cover to the axle housing
(alternative mounting)

31.5

÷ 38.5

3.15

÷ 3.85

Oil drainage plug **

÷ 62

4.9

÷ 6.2

Apply Loctite 5910 on the housing

** Apply Loctite 577 on the plug thread

*** Apply Loctite 573 on both sides of the gasket

SECTION A-B

SECTIONAL VIEW OF DIFFERENTIAL 450310

49359

Figure 3

SECTION A-A

REAR AXLES 450310

AILY

Revi - February 2005

Figure 4

87907

SECTIONAL VIEW OF HUB

REAR AXLES 450310

AILY

Revi - February 2005

TORQUE

COMPONENT

kgm

Wheel retaining nut

290

÷ 349

÷ 34.9

Screw securing drive shaft to the wheel hub

÷ 76

6.3

÷ 7.6

Ring nut retaining wheel hub bearing

618

÷ 667

61.8

÷ 66.7

Screw securing brake disc to wheel hub

÷ 76

6.9

÷ 7.6

Screw securing caliper mounting to shoe mounting

180

÷ 220

÷ 22

Screw securing shoe mounting to axle housing

÷ 97

8.5

÷ 9.7

Screw securing guard

0.8

Screw securing sensor mounting

÷ 7

0.5

÷ 0.7

Spread the surface of the drive shaft - wheel hub union with B-type sealant.

** When assembling the screws securing the timing sensor mounting, apply a few drops of LOCTITE 245 thread-lock onto

the thread of the corresponding holes of the bracket welded onto the axle arm.

REAR AXLES 450310

AILY

Revi - February 2005

TOOL NO.

DESCRIPTION

99305121

Hot air drier

99321024

Hydraulic trolley for removing and refitting wheels

99322215

Driving and steering axle overhaul stand

99341003

Single-acting rear axle

99341005

Reaction bridge

99341009

Pair of retainers
