HYDRO-PNEUMATIC SYSTEM - BRAKES
D
AILY
E
URO
4
COMPONENT
TORQUE
COMPONENT
Nm
kgm
Screw securing flange and brake disk to wheel hub (Front axle 5818 - 5819)
98.1
÷ 107.9
9.8
÷ 1..7
Screw securing flange and brake disk to wheel hub (Front axle 5823)
- torque clamping
43
÷ 53
4.3
÷ 5.3
- angle clamping
28.4º
÷ 30.4º
Screw securing brake disc to wheel hub (Front axle 5817)
19.5
÷ 24
2
÷ 2.5
Screws to fasten wheel
180
÷ 200
18
÷ 20
Screws to fasten brake caliper support to stub axle (Axle 5817 - 5818 - 5819)
176
÷ 217
18
÷ 22
Screws to fasten cover to stub axle
7
÷ 10
0,7
÷ 1
Wheel hub nut (Front axle 5817 - 5818 - 5819)
320
÷ 420
32
÷ 43
Nut securing wheel hub (Front axle 5823)
- torque clamping
50
÷ 60
5
÷ 6
- angle clamping
30.1º
÷ 34.1º
Screw securing caliper to caliper mounting (Front axle 5818 - 5819 - 5823)
Nut securing wheel (Rear axle 450311/1 - 450511)
290
÷ 349
29
÷ 34.9
Screw securing brake disk to half shaft (Rear axle NDA R.S.)
13
÷ 21
1.3
÷ 2.1
Screw securing drive shaft to wheel hub (Rear axle NDA R.G - 450511)
63
÷ 76
6.3
÷ 7.6
Ring nut retaining wheel hub bearing (Rear axle NDA R.S./R.G - 450511)
618
÷ 667
61.8
÷ 66.7
Screws securing brake disc to wheel hub (Rear axle NDA R.S./R.G - 450511)
69
÷ 76
6.9
÷ 7.6
Screws securing caliper moutning to shoe mounting (Rear axle NDA R.S./R.G - 450511)
177
÷ 217
18
÷ 22.1
Nut securing wheel (Rear axle 450517/2)
284.5
÷ 343.3
28.5
÷ 34.3
Screw to fasten cover and sheet metal guard to rear axle box (Rear axle NDA R.S.)
81
÷ 100
8.1
÷ 10
Screw to fasten cover and sheet metal guard (Rear axle NDA R.S.)
10
÷ 16
1
÷ 1.6
Ring nut securing bearing to half shaft (Rear axle NDA R.S.)
559
÷ 677
57
÷ 69
Screw securing shoe mounting to rear axle box (Rear axle NDA R.G. - 450511)
85
÷ 97
8.5
÷ 9.7
Screws securing sheet metal guard (Rear axle NDA R.G. - 450511)
8
0.8
Screw securing caliper to caliper mounting (Front axle 5817)
Sensor support retaining screw (Rear axle NDA R.G. - 450511 - 450517/2)
5
÷ 7
0.5
÷ 0.7
