![]() Figure 21 61663 Carry out the operations described for removal in reverse - fit the top flexible plugs (2) in the cross member (1) at the position found during disassembly; - fit the flexible plugs (4) onto the ends of the new leaf spring (3); - fit the leaf spring (3) into the cross member and support it with a hydraulic lift; - with two lifts arranged under the stub axles, lift them together, checking that the flexible plugs (4) of the leaf ⇒) of the leaf spring is aligned with the central holes ( ⇒) della traversa (1), of the cross member (1), max. error ±2 mm; - then complete refitting by tightening the screws or nuts to the required torque; - position the bottom flexible plugs (6) on the cover (7) at the position found during disassembly; - mount the cover (7) and tighten the screws and nuts to the required torque. The nylon self-locking nuts must be replaced with Refitting To block rotation of the pins of the swivel heads NOTE NOTE 24 FRONT MECHANICAL SUSPENSIONS D AILY E URO 4 |
