DEFINING THE CLASS OF DIAMETER OF THE MAIN JOURNALS AND CRANKPINS (Journals with nominal diameter) of the journals (1 = STD, 2 = -0.127), the other six digits, taken singly, give the class of diameter of each of the crankpins - The set of seven digits, on the right, refers to the main journals and is preceded by a single digit: the single digit shows the status of the journals (1 = STD, 2 = -0.127), the other seven digits, taken singly, give the class of diameter of each of the Figure 26 82.970 to 82.979 82.980 to 82.989 82.990 to 83.000 CLASS CRANKPIN NOMINAL DIAMETER 92.970 to 92.979 92.980 to 92.989 92.990 to 93.000 CLASS MAIN JOURNALS NOMINAL DIAMETER 19 CURSOR ENGINES F3A SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS Base - May 2007 |
