6E–540 TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS Electronic Ignition System Removal Procedure 1. Disconnect the negative battery cable. coil assemblies. 3. Remove the two screws that secure the ignition coil assemblies to the rocker cover. 060R200210 Legend (1) Ignition Coil Connectors 4. Remove the ignition coil assemblies and the spark plug boot from the spark plug. D Twist the ignition coil assemblies while pulling it 5. Use the appropriate spark plug socket in order to remove the spark plug from the engine. Installation Procedure NOTE: The plug must thread smoothly into the cylinder 1. Install the spark plug in the engine. Use the appropriate spark plug socket. Tighten D Tighten the spark plug to 18 N·m (13 lb ft.). 2. Install the ignition coil assemblies and spark plug boot over the spark plug. CAUTION: Ignition coil assembly #6 is different 060RY00002 Legend (1) Long Type Ignition Coil Assemblies (#1 ∼ #5) (2) Short Type Ignition Coil Assembly (#6) 3. Install ignition coil assemblies and tighten the fixing bolts to the specified torque. Torque: 4 N·m (35.4 Ib in) 060R200210 Legend (1) Ignition Coil Connectors 4. Connect the ignition coil connector at the ignition coil assemblies. 5. Connect the negative battery cable. |
