5A–24 BRAKE CONTROL SYSTEM Diagnosis By “ABS” Warning Light In the event that there is abnormality in the “ABS” warning or if the warning light is actuated during driving, trouble No. Condition “ABS” Warning Light Illumination Pattern Diagnostic 1 Warning light is actu- Normal 2 Warning light is not lit Warning light lighting circuit → Go to Chart B-1 3 Warning light remains Diagnostic trouble codes are 4 Warning light is actu- Diagnostic trouble codes are Diagnostic Trouble Codes (DTCs) When the warning light in the meter remains ON, the 1. How to display and erase DTCs: NOTE: D If DTCs are not displayed, harness C-4 connector D DTCs can be displayed also by TECH 2. Select mode 1. How to start DTC display: D Confirm that the vehicle has come to a complete D With IGN OFF, connect #12 terminal with #4 |
