POWER-ASSISTED STEERING SYSTEM 2A–21 3. Remove tie-rod assembly. To remove, move the boot toward the tie-rod end, 4. Remove oil line, mounting rubber and dust cover. Inspection and Repair Inspect the following parts for wear, damage or any Tie-rod End If looseness or play is found when checked by moving Tie-rod Assembly If the resistance is insufficient or play is felt when Rubber Parts If wear or damage is found through inspection, replace Reassembly 1. Install mounting rubber and dust cover (If removed). 2. Install oil line. Torque: 13 N· m (113 lb in) 3. Install tie-rod assembly with tab washer. Apply grease to ball joint, install tie-rod and tab Torque: 83 N·m (61 lb ft) After tightening, bend tab washer against width 4. Apply a thin coat of grease to the shaft for smooth installation. Then install bellows. 5. Install band and clip. 6. Install tie-rod end and tighten lock nut. Torque: 98 N·m (72 lb ft) Main Data and Specifications General Specifications Power Steering unit Type Rack and pinion Rack stroke 152 mm (5.98in) Lock to lock 3.64 |
