7C–16 CLUTCH 2. Use the pilot aligner J24547 to prevent the driven plate assembly (3) from falling free. 201RS001 Legend (2) Pressure Plate Assembly 3. Mark the flywheel, clutch cover and pressure plate lug for alignment when installing. 4. Remove the release bearing (4) from the transmission case. 201RS024 5. Remove the snap pin. Remove the shift fork pin and shift fork from the fulcrum bridge. 201RS025 6. Remove the fulcrum bridge bolts. Remove the fulcrum bridge (6) from the transmission case. 201RS026 |
