6E2–387 RODEO 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS D Damaged harness – Inspect the wiring harness for Reviewing the Failure Records vehicle mileage since the DTC P1107 – MAP Sensor Circuit Intermittent Low Voltage
Step Action Value(s) Yes No 1 Was the “On-Board Diagnostic (OBD) System Check” — Go to Step 2 Go to OBD System Check 2 Is DTC P0107 also set? — Go to DTC P0107 chart first Go to Step 3 3 Check for a poor 5 volt reference circuit or MAP signal Was a problem found? — Go to Step 8 Go to Step 4 4 Check the MAP signal circuit between the MAP sensor Was a problem found? — Go to Step 9 Go to Step 7 5 Check for an intermittent short to ground on the 5 volt D MAP sensor D EGR valve D TP sensor Was a problem found? — Go to Step 9 Go to Step 6 6 Check for a poor 5 volt reference terminal connection at Was a problem found? — Go to Step 8 Go to Step 7 7 Check for an intermittent open or a faulty splice in the 5 Was a problem found? (If no, start with the diagnosis — Go to Step 9 Refer to Diagnostic Aids 8 Replace the faulty harness connector terminal(s) for Is the action complete? — Verify repair — 9 Repair intermittent open/short circuit in the wiring Is the action complete? — Verify repair — |
