1A–26 HEATING, VENTILATION AND AIR CONDITIONING (HVAC) Control Panel Illumination Bulb Control Panel Illumination Bulb and 865RY00018 Legend (1) Control Lever Assembly Removal 1. Disconnect the battery ground cable. D Refer to Control Lever Assembly in this section. 3. Pull out the bulb socket from the panel by turning it counterclockwise. 4. Pull the illumination bulb from the socket. Installation To install, follow the removal steps in the reverse order. Resistor Resistor and Associated Parts 840RW001 Legend (1) Duct (Heater only) Removal 1. Disconnect the battery ground cable. Installation To install, follow the removal steps in the reverse order. |
