6A-82 ENGINE MECHANICAL (C22NE, 22LE, 20LE) Crankshaft, Cylinder Block (continued) Piston Rings Square ring Height mm 1.5 Tapered ring Height mm 1.5 Oil scraper Height mm 3 Ring gap offset 180 ° Note that the upper steel band ring gap is offset 25 to 50mm to Piston Pin Length mm 61.5 Diameter mm 21 Type Shrunk into con-rod Play mm in piston 0.011 to 0.014 in con-rod none Installation When installing piston pins, ° C in oil bath. This temperature should under no Crankshaft, Cylinder Block (continued) The permissible weight variation of con-rods without piston and |
