7B–42 MANUAL TRANSMISSION 5. Using a thickness gauge, measure the clearance between the 4th block ring back and gear spline Standard: 0.75 – 1.65 mm (0.030 – 0.065 in) 226RW064 6. Check the braking effect of the block ring. Turn the block ring in one direction while pushing it to 226RW060 7. Install the needle roller bearing. 2. Reassemble the mainshaft assembly. NOTE: Apply all parts with engine oil before installing 3. Inspect block ring 1. Using a thickness gauge, measure the clearance between the synchronizer ring back and gear Gear Standard Clearanse 1st 0.80 – 1.60 mm (0.032 – 0.063 in) 2nd 0.65 – 1.75 mm (0.026 – 0.069 in) 3rd 0.75 – 1.65 mm (0.030 – 0.065 in) 226RW105 2. Turn the synchronizer ring in one direction while pushing it to the gear cone. Check that the ring 226RW106 |
