6E–245 3.2L ENGINE DRIVEABILITY AND EMISSIONS Be certain of the type of connector/terminal before Wire Harness Repair: Twisted Shielded Cable Removal Procedure 1. Remove the outer jacket. mylar. 047 3. Untwist the conductors. 048 Installation Procedure 1. Splice the wires using splice clips and rosin core solder. 2. Wrap each splice to insulate. (uninsulated) wire. 049 4. Tape over the whole bundle to secure. 050 Twisted Leads Removal Procedure 1. Locate the damaged wire. |
