Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Manual - part 277

Immobilizer system Electrical wiring



Gasoline Engine (C22NE 2.2L/22LE 2.2L/20LE 2.0L)







Immobilizer system Electrical wiring



Diesel Engine    (Mechanical Control , 4JG2 3.1L/4JB1 2.8L/4JA1 2.5L)







Immobilizer system Electrical wiring



Diesel Engine    (Electrical Control , 4JA1-TC 2.5L/4JH1-TC 3.0L)



IMM-WE-0121

You are requested to order this manual using the
manual number that is shown above.

This manual is applicable for vehicles in Europe
except the USA and Canada.

All rights reserved. This manual may not be
reproduced in whole or in part, without the
permission in writing of ISUZU MOTORS LIMITED.

Issued by

ISUZU MOTORS LIMITED

INTERNATIONAL SERVICE DEPARTMENT

Tokyo, Japan

First edition April., 2002
