Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Manual - part 2061

3C-48  FRONT SUSPENSION

7.  GRATING TIRE NOISE

Checkpoint

Trouble Cause

Countermeasure

Tire pressure

Knuckle spindle and steering

linkage

Adjust

Replace

Improper

Deformed

Suspension fixing bolt

Replace

Adjust

Loose

Incorrect

OK

NG

NG

NG

NG

OK

OK

Wheel alignment

FRONT SUSPENSION  3C-49

8.  EXCESSIVELY OR PARTIALLY WORN TIRE

Checkpoint

Trouble Cause

Countermeasure

Brake adjustment

Wheel alignment

Adjust

Adjust

Incorrect

Incorrect

Front wheel bearing

Replace

Adjust

Faulty

Improper

OK

NG

NG

NG

NG

OK

OK

Tire pressure

Tire rotation

Rotate tires at recomended

intervals

Not rotated

OK

NG

3C-50  FRONT SUSPENSION

SPECIAL SERVICE TOOL (C22, C20 Series Engine Model)

ITEM NO.

ILLUSTRATION

PART NO.

PART NAME

SUL-1

5-8840-0256-0

(J-29755)

Upper link bushing

remover & installer

SUL-6

5-8840-0257-0

(J-29756)

Lower link bushing

remover & installer

SUL-3

5-8840-2000-0

(J-5822)

Knuckle needle bearing

remover

OTL-2

5-8840-0019-0

(J-23907)

Sliding hammer (small)

SUL-5

5-8840-2124-0

(J-36384)

Rear lower link bushing

remover & installer kit

SUL-4

5-8840-2123-0

(J-36833)

Front lower link bushing

remover & installer kit

SUL-10

5-8840-2128-0

(J-36838)

knuckle needle bearing

installer

OTL-1

5-8840-0007-0

(J-8092)

Driver handle

SUL-9

5-8840-2127-0

(J-36838)

Knuckle oil seal installer

REAR SUSPENSION  3D-1

SECTION 3D

REAR SUSPENSION

TABLE OF CONTENTS

PAGE

Main Data and Specifications........................................................................................... 3D- 2

Torque Specifications ....................................................................................................... 3D- 3

Special Parts Fixing Nuts and Bolts ........................................................................... 3D- 3

Rear Suspension ............................................................................................................... 3D- 4

General Description...................................................................................................... 3D- 4

Disassembly .................................................................................................................. 3D- 5

Inspection and Repair .................................................................................................. 3D- 7

Reassembly ................................................................................................................... 3D- 9

Troubleshooting ................................................................................................................ 3D- 12

INDEX
