PRINTED IN JAPAN

No. TFSSW-WE-0001A

WORKSHOP MANUAL

TF SERIES

STEERING SUSPENSION,

WHELLS AND TIRES

SECTION 3

NOTICE

Before using this Workshop Manual to assist you in performing vehicle

service and maintenance operations, it is recommended that you

carefully read and thoroughly understand the information contained in

Section - OA under the headings “GENERAL REPAIR

INSTRUCTIONS” and “HOW TO USE THIS MANUAL”.

All material contained in this Manual is based on the latest product

information available at the time of publication.

All rights are reserved to make changes at any time without prior

notice.

THIS MANUAL INCLUDES FOLLOWING SECTIONS

SECTION NO.

CONTENTS

3A

Front Alignment

3B

Steering

3C

Front Suspension

3D

Rear Suspension

3E

Wheels and Tires
