No. TFMSG-WE-981

PRINTED IN JAPAN







WORKSHOP MANUAL

TF SERIES

TRANSMISSION

JR405E MODEL

SECTION 7A








CONSTRUCTION AND FUNCTION  7A1-1



SECTION 7A1

CONSTRUCTION AND FUNCTION

TABLE OF CONTENTS



PAGE

DESCRIPTION  ...............................................................................................................................7A1- 3

CONSTRUCTION  .....................................................................................................................7A1- 3
MAIN DATA AND SPECIFICATION  .....................................................................................7A1- 4
NUMBER PLATE LOCATION  ...............................................................................................7A1- 5
ELECTRONIC CONTROL COMPONENTS LOCATION  ...................................................7A1- 6
TRANSMISSION CONTROL UNIT (TCM) PERIPHERAL CIRCUIT  ...............................7A1- 7
STRUCTURE AND FUNCTION OF COMPONENT  ...........................................................7A1- 8
TORQUE CONVERTER (WITH LOCK-UP FUNCTION)  ...................................................7A1- 8
OIL PUMP  .................................................................................................................................7A1- 9
INPUT SHAFT  ..........................................................................................................................7A1- 10
OUTPUT SHAFT  ......................................................................................................................7A1- 10
GEAR SHIFTING MECHANISM  ............................................................................................7A1- 10
CONTROL VALVE  ...................................................................................................................7A1- 14
OIL PASSAGE  ..........................................................................................................................7A1- 19
PARKING FUNCTION  .............................................................................................................7A1- 20
INHIBITOR SWITCH  ................................................................................................................7A1- 21
TURBINE SENSOR  .................................................................................................................7A1- 22
SPEED SENSOR  .....................................................................................................................7A1- 22
THROTTLE POSITION SENSOR (TPS)  ..............................................................................7A1- 23
ENGINE SPEED SENSOR (=TDC SENSOR)  ....................................................................7A1- 23
BRAKE SWITCH  ......................................................................................................................7A1- 24
MODE SELECT SWITCH  .......................................................................................................7A1- 24
TRANSMISSION CONTROL MODULE (TCM)  ...................................................................7A1- 25

CONTROL MECHANISM  ............................................................................................................7A1- 26

CONTENT OF FUNCTION AND CONTROL  .......................................................................7A1- 26
CONTROL ITEM, INPUT AND OUTPUT  .................................................................... 7A1- 29
LINE PRESSURE CONTROL  ..................................................................................... 7A1- 30
