WORKSHOP MANUAL

TF SERIES

HEATING AND AIR CONDITIONING

SECTION 1

NOTICE

Before using this Workshop Manual to assist you in performing vehicle

service and maintenance operations, it is recommended that you

carefully read and thoroughly understand the information contained in

Section - OA under the headings “GENERAL REPAIR

INSTRUCTIONS” and “HOW TO USE THIS MANUAL”.

All material contained in this Manual is based on the latest product

information available at the time of publication.

All rights are reserved to make changes at any time without prior

notice.

HEATING AND AIR CONDITIONING  1-1

SECTION 1

HEATER AND AIR CONDITIONING

TABLE OF CONTENTS

PAGE

General Description......................................................................................................... 1- 3

Main Data and Specifications ......................................................................................... 1- 8

Special Parts Fixing Nuts and Bolts .............................................................................. 1- 9

Servicing........................................................................................................................... 1-12

Precautions For Refrigerant - 134a (R-134a) Air conditioning system................... 1-12

Condenser ........................................................................................................................ 1-26

Removal and Installation ............................................................................................ 1-26

Compresser...................................................................................................................... 1-28

Removal and Installation ............................................................................................ 1-28

Disassembly ................................................................................................................ 1-34

Reassembly ................................................................................................................. 1-39

Heater Unit........................................................................................................................ 1-45

Removal and Installation ............................................................................................ 1-45

Disassembly and Reassembly ................................................................................... 1-47

Evaporator........................................................................................................................ 1-48

Removal and Installation ............................................................................................ 1-48

Disassembly and Reassembly ................................................................................... 1-49

Blower Unit Assembly ..................................................................................................... 1-51

Removal and Installation ............................................................................................ 1-51

Disassembly and Reassembly ................................................................................... 1-53
