8–100 ELECTRICAL-BODY AND CHASSIS

CIRCUIT DIAGRAM (4ZD1 GASOLINE ENGINE – SAUDI ARABIA)

D08RV942

5

C-78

1

C-78

FENDER-RH

C-2

1.25B

P-1

P-5

+

_

P-10

20B/Y

ENG.

P-7

FRAME

5B/Y

15B/R

P-2

IGN.B1
40A

3W/B

3W/B

矢崎

4556

発注者

発注日

作業番号

C-41

ACC

IG2

ST

IG1

3

H-7

2

OFF

C-41

6

B2

B1

3B/R

3B/R

3B/R

0.85Y

0.3BR/Y

0.3BR/Y

0.5L/Y

0.85L/Y

0.85L/P

0.5L/P

STARTER SW

CB-7
15A METER

CB-3
15A ENGINE-1

EB-14
10A AUTO CHOKE

0.85W/G

5

H-7

0.5L/Y

0.5L/Y

CB-4
10A ENGINE-2

0.85W/G

0.5W/G

0.5B/R

0.5R/G

0.5Y/G

0.5B

0.5L

0.5B

0.5B

0.5L

0.5B/R

14

H-8

6

H-5

1

M-1

2

H-5

2

C-78

3

C-78

3

H-6

1

M-2

2ND SW

0.85L/P

0.85L/Y

1

M-3

1

M-4

TOP-3RD SW

4

C-66

3

C-66

COASTING
RICHER
(CARBURETOR)

7

B-23

9

B-24

OIL TEMPERATURE
WARNING LIGHT
(METER)

RELAY;
CHARGE

0.85W/L

0.5B

3B

0.5B

AC GENERATOR(L)

2

C-66

AUTO CHOKE
(CARBURETOR)

1

C-60

2

C-60

−

＋

2

C-68

1

C-68

DISTRIBUTOR

6

C-78

2

C-77

1

C-77

CLUTCH
SW

1

C-70

OIL TEMPERATURE
SENSOR

1

C-40

2

C-40

ACCEL.
SW

X - 5

4

X - 5

5

2

X - 5

3

X - 5

1

X - 5

ENGINE SPEED SENSOR

ENGINE SPEED SENSOR

ELECTRICAL-BODY AND CHASSIS 8–101

INSPECTION AND REPAIR

4

1

3

2

5

2

1

3

4

5

060RV005

Charge relay

Check continuity between the relay terminals.

3 – 5  . . . . . . . . . . . . . .

Continuity

1 – 5  . . . . . . . . . . . . . .

No continuity

(When battery voltage is applied between 2 and 4)

3 – 5  . . . . . . . . . . . . . .

No continuity

1 – 5  . . . . . . . . . . . . . .

Continuity

X-5

4

1

3

2

5

2

1

3

4

5

060RV005

X-10

EFE heater relay

Check continuity between the relay terminals.

1 – 5  . . . . . . . . . . . . . .

No continuity

(When battery voltage is applied between 2 and 4)

1 – 5  . . . . . . . . . . . . . .

Continuity

8–102 ELECTRICAL-BODY AND CHASSIS

QOS SYSTEM

PARTS LOCATION (LHD)

RELAY & FUSE BOX

(X-9)

H-4

B-24

C-41

H-6
H-7

E-49

E-37

E-50

E-41

C-46

H-8

C-2

C-5,C-6
C-7

D08RVA25

ELECTRICAL-BODY AND CHASSIS 8–103

PARTS LOCATION (RHD)

H-4

B-24

C-41

E-49

E-37

E-50

E-41

C-5
C-6
C-7

RELAY & FUSE BOX

(X-9)

C-2

H-6
H-7

D08RVA26
