Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Manual - part 1216
8-204 ELECTRICAL-BODY AND CHASSIS
INSPECTION AND REPAIR
OVERDRIVE OFF SWITCH
Overdrive Off Switch Connections
Terminal
No.
SW position
2
4
1
3
ON
OFF
OVERDRIVE OFF RELAY
Check continuity between the relay terminals.
3
-
5
............................. Continuity
(When battery voltage is applied between
2
and
4
)
3
-
5
............................. No continuity
