4JA1-TC/4JH1-TC ENGINE DRIVEABILITY AND EMISSIONS 6E–327 8 Using the DVM and check the “Check Engine” lamp 1. Ignition “Off”, engine “Off”. 2. Install the breaker box as type A. (ECM disconnected) Ref. Page 6E-81 3. Remove the meter connector. 4. Check the circuit for open or short to ground circuit. Was the problem found? Breaker box is not available: 1. Ignition “Off”, engine “Off”. 2. Disconnect the ECM connector. 3. Remove the meter connector. 4. Check the circuit for open or short to ground circuit. Was the problem found? — Repair faulty verify repair Go to Step 9 Step Action Value(s) Yes No 42 42 2 6 B-23 4JA1-TC B-23 4JH1-TC 42 2 42 6 C-56 4JA1-TC B-23 C-56 4JH1-TC B-23 |
