TM-258 < DISASSEMBLY AND ASSEMBLY > ASSEMBLY 3. Install oil pump assembly in transmission case. CAUTION: Apply ATF to oil pump bearing. 4. Apply recommended sealant (Genuine RTV Silicone Sealant or equivalent. Refer to GI-15, "Recommended Chemical Products .) to oil pump assembly as shown. CAUTION: Completely remove all moisture, oil, old sealant and any foreign material from the oil pump bolts and oil pump bolt mating surfaces. 5. Tighten oil pump bolts to specified torque. CAUTION: Apply ATF to oil pump bushing. 6. Install O-ring to input clutch assembly. CAUTION: • Do not reuse O-ring. • Apply ATF to O-ring. 7. Install converter housing to transmission case and tighten bolts to specified torque. CAUTION: Do not reuse self-sealing bolt (A). SCIA2811E SCIA5321E Oil pump bolts : 48 N·m (4.9 kg-m, 35 ft-lb) SCIA2300E SCIA5011E Converter housing bolt : 52 N·m (5.3 kg-m, 38 ft-lb) Self-sealing bolt (A) : 61 N·m (6.2 kg-m, 45 ft-lb) WCIA0662E |
