Infiniti QX56 (JA60). Manual - part 740

PG

HARNESS

PG-47

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

ENGINE ROOM HARNESS (PASSENGER COMPARTMENT)

ABMIA1201GB

A3

E10

W/10

: To M6

B3

E38

W/4

: Stop lamp switch

C4 E20

B/8

: Accelerator pedal position
  (APP) sensor

A3

E43

BR/2

: ICC brake switch (with ICC)

C4 E26

W/16

: To M91

B3

E109

GR/2

: Pedal adjusting motor assembly

B4

E29

Y/4

: To M10

B3

E110

GR/3

: Pedal adjusting motor assembly

G3 E33

B/1

: To M66

G4 E139

W/8

: To B107

PG-48

< COMPONENT DIAGNOSIS >

HARNESS

ENGINE CONTROL HARNESS

A3

E34

W/24

: To B40

F3

E142

W/24

: Transfer control unit

A4

E35

W/12

: To B41

F3

E143

GR/24

: Transfer control unit

A4

E36

W/2

: To B42

G3 E152

SMJ

: To M31

B3

E37

BR/2

: ASCD brake switch (with ASCD)

ABMIA1202GB

PG

HARNESS

PG-49

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

D5 F3

B/1

: A/C Compressor

D4

F42

GR/2

: Fuel injector No. 5

D5 F4

GR/1

: Oil pressure switch

D3

F45

GR/2

: Fuel injector No. 7

D2 F5

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 2)

B4

F46

B/3

: Power steering pressure sensor

C4 F6

GR/3

: Ignition coil No. 2 (with power transistor)

E4

F47

GR/3

: Ignition coil No. 1 (with power transistor)

C3 F7

GR/3

: Ignition coil No. 4 (with power transistor)

E4

F48

GR/3

: Ignition coil No. 3 (with power transistor)

C3 F8

GR/3

: Ignition coil No. 6 (with power transistor)

E4

F49

GR/3

: Ignition coil No. 5 (with power transistor)

E2

F9

G/10

: A/T assembly

D4

F50

B/6

: Electric throttle control actuator

C3 F10

—

: Engine ground

E4

F51

GR/3

: Ignition coil No. 7 (with power transistor)

D3 F11

B/3

: Crankshaft position sensor (POS)

D2

F52

GR/3

: Ignition coil No. 8 (with power transistor)

E1

F12

G/4

: Heated oxygen sensor 2 (bank 2)

E5

F53

B/6

: Mass air flow sensor

F2

F13

G/4

: Heated oxygen sensor 2 (bank 1)

B2

F54

B/81

: ECM

B2

F14

W/24

: To E5

F1

F55

B/2

: ATP switch

D4 F15

GR/2

: EVAP canister purge volume control
  solenoid valve

F2

F56

B/8

: Transfer terminal cord assembly

E5

F16

—

: Engine ground

G1

F57

B/2

: Transfer motor

C4 F18

GR/2

: Fuel injector No. 2

F2

F58

GR/6

: Transfer control device

D4 F20

GR/2

: Fuel injector No. 4

F2

F59

B/2

: Wait detection switch

F4

F21

GR/2

: Condenser-1

F1

F60

GR/2

: Neutral-4LO switch

D3 F22

GR/2

: Fuel injector No. 6

D5

F61

G/2

: Intake valve timing control solenoid valve
  (bank 1)

D4 F23

B/3

: Camshaft position sensor (phase)

D5

F62

B/3

: Intake valve timing control position sensor
  (bank 1)

D4 F26

B/6

: To F101

C4

F63

G/2

: Intake valve timing control solenoid valve
  (bank 2)

E3

F27

  /1

: Starter motor

C4

F64

B/3

: Intake valve timing control position sensor
  (bank 2)

E3

F28

GR/1

: Starter motor

E3

F65

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 1)

D4 F30

GR/2

: Fuel injector No. 1

C2

F68

GR/2

: Water valve

D3 F31

GR/2

: Fuel injector No. 8

Engine control sub-harness

B2

F32

W/16

: To E2

C3

F101

B/6

: To F26

C2 F33

W/16

: To E19

C3

F102

B/2

: Knock sensor (bank 1)

C2 F34

W/2

: To E39

C3

F103

GR/2

: Engine coolant temperature sensor

B3

F39

  /1

: Fusible link box (battery)

C3

F104

B/2

: Knock sensor (bank 2)

D4 F41

GR/2

: Fuel injector No. 3

PG-50

< COMPONENT DIAGNOSIS >

HARNESS

CHASSIS HARNESS

AWMIA0113GB

G2 C1

SMJ

: To E41

C4 C10

BR/2

: Rear wheel sensor RH

B5

C2

B/7

: Trailer

C4 C11

BR/2

: Rear wheel sensor LH

A3

C3

GR/8

: To C101

Rear sonar sensor sub-harness

C3 C4

GR/3

: Evap control system pressure sensor

A4

C101

GR/8

: To C3

D2 C5

GR/5

: Fuel level sensor unit and fuel pump

A3

C102

B/3

: Rear sonar sensor LH outer
