AUTOMATIC DRIVE POSITIONER CONTROL UNIT

ADP-175

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

Removal and Installation

INFOID:0000000005147593

CAUTION:

When removing and installing, use shop cloths to protect parts from damage.

REMOVAL

1. Disconnect the battery negative terminal.
2. Remove the instrument driver lower panel. Refer to

IP-12, "Removal and Installation"

.

3. Remove the screw from the automatic drive positioner control

unit (1).

4. Remove automatic drive positioner control unit (1) from bracket

and disconnect electrical connectors.

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

Clamp the harness in position.

NOTE:

After installing the automatic drive positioner control unit, perform additional service when disconnecting bat-

tery negative terminal. Refer to

ADP-8, "Special Repair Requirement"

.

ALIIA0241ZZ

ADP-176

< ON-VEHICLE REPAIR >

SEAT MEMORY SWITCH

SEAT MEMORY SWITCH

Removal and Installation

INFOID:0000000005147594

Refer to

INT-11, "Removal and Installation"

 for removal and installation of seat memory switch.

DOOR MIRROR REMOTE CONTROL SWITCH

ADP-177

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

DOOR MIRROR REMOTE CONTROL SWITCH

Removal and Installation

INFOID:0000000005147595

The door mirror remote control switch is part of the power window switch assembly. Refer to

INT-11, "Removal

and Installation"

 for removal and installation of door mirror remote control switch.

ADP-178

< ON-VEHICLE REPAIR >

PEDAL ADJUSTING MOTOR

PEDAL ADJUSTING MOTOR

Removal and Installation

INFOID:0000000005147596

Refer to

ACC-4, "Removal and Installation"

 for accelerator pedal and

BR-19, "Removal and Installation"

 for

brake pedal when removing pedal adjusting motors.
