I The threads in one or more of the converter bolt holes are damaged. I Transmission failure did not display evidence of damaged or worn internal parts, steel particles or clutch I Vehicle has been exposed to high mileage (only). The exception may be where the torque converter clutch ATF COOLER SERVICE NBAT0004S02 Replace ATF cooler if excessive foreign material is found in oil pan or clogging strainer. OBD-II SELF-DIAGNOSIS NBAT0004S03 I A/T self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through I The self-diagnostic results indicated by the MIL are automatically stored in both the ECM and TCM I The following self-diagnostic items can be detected using ECM self-diagnostic results mode* only when − PNP switch − A/T 1st, 2nd, 3rd, or 4th gear function − A/T TCC S/V function (lock-up) *: For details of OBD-II, refer to EC-59, “Introduction”. I Certain systems and components, especially those related to OBD, may use the new style slide- Wiring Diagrams and Trouble Diagnosis NBAT0005 When you read wiring diagrams, refer to the following: I GI-11, “HOW TO READ WIRING DIAGRAMS”. I EL-9, “POWER SUPPLY ROUTING” for power distribution circuit. When you perform trouble diagnosis, refer to the following: I GI-35, “HOW TO FOLLOW TEST GROUP IN TROUBLE DIAGNOSIS”. I GI-24, “HOW TO PERFORM EFFICIENT DIAGNOSIS FOR AN ELECTRICAL INCIDENT”. GI MA EM LC EC FE TF PD AX SU BR ST RS BT HA SC EL IDX PRECAUTIONS Service Notice or Precautions (Cont’d) AT-9 |
