DTC P1572 ICC BRAKE SWITCH
EC-595
C
D
E
F
G
H
I
J
K
L
M
A
EC
DTC Confirmation Procedure
NBS0024F
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
●
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait
at least 10 seconds before conducting the next test.
●
Procedure for malfunction B is not described here. It takes extremely long time to complete procedure for
malfunction B. By performing procedure for malfunction A, the incident that causes malfunction B can be
detected.
TESTING CONDITION:
Steps 4 and 5 may be conducted with the drive wheels lifted in the shop or by driving the vehicle. If a
road test is expected to be easier, it is unnecessary to lift the vehicle.
WITH CONSULT-II
1.
Start engine (VDC switch OFF).
2.
Select “DATA MONITOR” mode with CONSULT-II.
3.
Press MAIN switch and make sure that CRUISE lamp lights up.
4.
Drive the vehicle for at least 5 consecutive seconds under the
following conditions.
If 1st trip DTC is detected, go to
EC-597, "Diagnostic Procedure"
.
If 1st trip DTC is not detected, go to the following step.
5.
Drive the vehicle for at least 5 consecutive seconds under the following conditions.
6.
If 1st trip DTC is detected, go to
EC-597, "Diagnostic Procedure"
WITH GST
Follow the procedure “WITH CONSULT-II” above.
VHCL SPEED SE
More than 30 km/h (19 MPH)
Selector lever
Suitable position
PBIB2386E
VHCL SPEED SE
More than 30 km/h (19 MPH)
Selector lever
Suitable position
Driving location
Depress the brake pedal for more than
five seconds so as not to come off from
the above-mentioned vehicle speed.
