PREPARATION

FFD-3

C

E

F

G

H

I

J

K

L

M

A

B

FFD

PREPARATION

PFP:00002

Special Service Tools

NDS000EM

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number
(Kent-Moore No.)
Tool name

Description

KV381054S0
(J-34286)
Puller

●

Removing front oil seal

●

Removing side oil seal(right side)

●

Removing side bearing outer race

ST33400001
(J-26082)
Drift
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.

●

Installing front oil seal

●

Installing side oil seal (right side)

KV38102510
(

—

)

Drift
a: 71 mm (2.80 in) dia.
b: 65 mm (2.56 in) dia.

Installing front oil seal

KV38102100
(J-25803-01)
Drift
a: 44 mm (1.73 in) dia.
b: 36 mm (1.42 in) dia.
c: 24.5 mm (0.965 in) dia.

Installing side oil seal (left side)

ST30032000
(J-26010-01)
Drift
a: 80 mm (3.15 in) dia.
b: 38 mm (1.50 in) dia.
c: 31 mm (1.22 in) dia.

●

Installing pinion rear bearing inner race

●

Installing side shaft

ST3127S000
(J-25765-A)
Preload gauge
1: GG91030000

(J-25765)
Torque wrench

2: HT62940000

(

—

)

Socket adapter (1/2

″

)

3: HT62900000

(

—

)

Socket adapter (3/8

″

)

Measuring pinion bearing preload and total
preload

ZZA0601D

ZZA0702D

ZZA0838D

ZZA1046D

S-NT107

NT124

FFD-4

PREPARATION

KV10111100
(J-37228)
Seal cutter

Removing carrier cover

ST3306S001
(J-22888-D)
Differential side bearing puller set
1: ST33051001

(J-22888-20)
Puller

2: ST33061000

(J-8107-2)
Base
a: 28.5 mm (1.122 in) dia.
b: 38 mm (1.50 in) dia.

Removing and installing side bearing inner
race

ST30031000
(J-22912-01)
Replacer

Removing pinion rear bearing inner race

KV31103000
(J-38982)
Drift
a: 49 mm (1.93 in) dia.
b: 70 mm (2.76 in) dia.

Installing side bearing outer race

ST30611000
(J-25742-1)
Drift bar

Installing side bearing outer race (Use with
KV31103000)

ST37820000
(

—

)

Drift
a: 39 mm (1.54 in) dia.
b: 72 mm (2.83 in) dia.

Installing pinion front and rear bearing outer
race

ST33230000
(J-25805-01)
Drift
a: 51 mm (2.01 in) dia.
b: 41 mm (1.61 in) dia.
c: 28.5 mm (1.122 in) dia.

Installing side bearing inner race

Tool number
(Kent-Moore No.)
Tool name

Description

S-NT046

NT072

ZZA0700D

ZZA1113D

S-NT090

ZZA0836D

ZZA1046D

PREPARATION

FFD-5

C

E

F

G

H

I

J

K

L

M

A

B

FFD

Commercial Service Tools

NDS000EN

KV38100200
(

—

)

Drift
a: 65 mm (2.56 in) dia.
b: 49 mm (1.93 in) dia.

Installing side shaft oil seal

(J-8129)
Spring gauge

Measuring turning torque

Tool number
(Kent-Moore No.)
Tool name

Description

ZZA1143D

NT127

Tool name

Description

Flange wrench

Removing and installing drive pinion lock nut

Spacer
a: 60 mm (2.36 in) dia.
b: 36 mm (1.42 in) dia.
c: 30 mm (1.18 in)

Installing pinion front bearing inner race

Power tool

Loosening bolts and nuts

NT035

ZZA1133D

PBIC0190E

FFD-6

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

PFP:00003

NVH Troubleshooting Chart

NDS000EO

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference page

Re

fe

r to



FF

D

-2

4

, "

INSPECTI

ON AFTER DI

S

ASSEM

BL

Y

"

 .

Re

fe

r to



FF

D

-1

7

, "

T

o

ot

h C

o

nt

ac

t"

 .

Re

fe

r to



FF

D

-2

4

, "

INSPECTI

ON AFTER DI

S

ASSEM

BL

Y

"

 .

Re

fe

r to



FF

D

-1

9

, "

Bac

k

lash

"

 .

Re

fe

r to



FF

D

-1

9

, "

C

o

m

p

an

io

n F

lan

ge

R

u

nou

t"

 .

Re

fe

r to



FF

D

-8

, "

Ch

e

c

k

in

g

 Dif

fe

re

n

tia

l Ge

a

r Oi

l"

 .

NVH

in

 PR s

e

c

tio

n

.

NVH

in

 F

AX, RAX,

 FSU a

n

d

 RSU s

e

c

tio

n

s

.

NVH in

 W

T

 s

e

c

ti

o

n

.

NVH in

 W

T

 s

e

c

ti

o

n

.

NVH

in

 F

AX a

n

d

 RAX s

e

c

tio

n

.

NVH

in

 BR s

e

c

tio

n

.

NVH

in

 PS s

e

c

tio

n

.

Possible cause and SUSPECTED PARTS

G

ear

 t

oot

h

ro

ugh

G

ear

 c

ont

act

 i

m

pr

oper

T

o

o

th su

rf

aces

 w

o

rn

Back

la

sh i

n

cor

rec

t

C

o

m

p

ani

on

 f

lange

 ex

cess

iv

e

ru

n

out

G

ear

 o

il i

m

pr

oper

PROPELLER SHAFT

AXLE AND

S

U

S

PENSI

ON

TIR

E

S

ROAD W

H

EEL

DRI

VE SHAFT

BRAKES

STEERING

Symptom

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×
