TROUBLE DIAGNOSIS EC-117 [VQ35DE] C D E F G H I J K L M A EC 21 W Fuel injector No. 5 [Engine is running] ● Warm-up condition ● Idle speed NOTE: BATTERY VOLTAGE (11 - 14V) [Engine is running] ● Warm-up condition ● Engine speed: 2,000 rpm BATTERY VOLTAGE (11 - 14V) 24 O A/F sensor 1 heater [Engine is running] ● Warm-up condition ● Idle speed Approximately 5V 25 P/B Heated oxygen sensor 2 [Engine is running] ● Engine speed: Below 3,600 rpm after the – Engine: After warming up – Keeping the engine speed between 3,500 0 - 1.0V [Ignition switch: ON] ● Engine stopped [Engine is running] ● Engine speed: Above 3,600 rpm BATTERY VOLTAGE 32 R/G EVAP control system pres- [Ignition switch: ON] Approximately 1.8 - 4.8V TER- MINAL NO. WIRE COLOR ITEM CONDITION DATA (DC Voltage) PBIB0042E PBIB0043E PBIB1584E |
