SRS-30 TROUBLE DIAGNOSIS 4. Touch “TROUBLE DIAG RECORD”. NOTE: 5. Diagnostic code is displayed on “TROUBLE DIAG RECORD”. 6. Touch “PRINT”. 7. SRS-30, "DTC No. Index (“SELF- DIAG [PAST]” or “TROUBLE DIAG RECORD”)" 8. Touch “BACK” key of CONSULT-II until “SELECT SYSTEM” 9. Turn ignition switch OFF, then turn off and disconnect CON- 10. Repair the system as outlined by the “Repair order” in “Intermit- tent Malfunction Diagnostic Code Chart”, that corresponds to the SRS-27, "DIAGNOSTIC PROCEDURE 3" DTC No. Index (“SELF-DIAG [PAST]” or “TROUBLE DIAG RECORD”) SRS697 SHIA0182E Diagnostic item Explanation Repair order “Recheck SRS at each replacement” NO DTC IS When malfunction is ● Low battery voltage (Less than 9V) ● Go to ● No malfunction is detected. ● Go to DRIVER AIR BAG ● Driver air bag module circuit is open (including the spiral cable). 1. Visually check the wiring harness connection. 2. Replace the harness if it has visible damage. 3. If the harness check result is OK, replace driver air bag module diag- DRIVER AIR BAG ● Driver air bag module circuit is shorted to a power supply circuit DRIVER AIR BAG ● Driver air bag module circuit is shorted to ground (including the DRIVER AIR BAG ● Driver air bag module circuit is shorted between lines. |
