REAR WINDOW DEFOGGER

GW-63

C

D

E

F

G

H

J

K

L

M

A

B

GW

TIWM1157E

GW-64

REAR WINDOW DEFOGGER

TIWM1011E

REAR WINDOW DEFOGGER

GW-65

C

D

E

F

G

H

J

K

L

M

A

B

GW

TIWM1491E

GW-66

REAR WINDOW DEFOGGER

Terminal and Reference Value for BCM

NIS000F6

Terminal and Reference Value for IPDM E/R

NIS000F7

Ter-

minal

Wire

color

Item

Signal input/

output

Condition

Voltage (V)

(Approx.)

Ignition

switch

Operation or condition

9

L/R

Rear window defogger
switch signal

Input ON

When rear window defogger switch is
pressed.

0

When rear window defogger switch is
OFF.

5

38

W/L

Ignition switch ON or
START

Input

ON

Ignition switch (ON or START position)

Battery voltage

39

L

CAN- H

Input/Output

—

—

—

40

P

CAN- L

Input/Output

—

—

—

42

GY

Power source (Fuse)

Input

OFF

—

Battery voltage

52

B

Ground

—

ON

—

0

55

W/R

Power source (Fusible link)

Input

OFF

—

Battery voltage

Ter-

minal

Wire

color

Item

Signal input/

output

Condition

Voltage (V)

(Approx.)

Ignition

switch

Operation or condition

5

W

BAT power supply

Output

OFF

—

Battery voltage

6

R

BAT power supply

Output

OFF

—

Battery voltage

38

B/R

Ground (Power)

—

ON

—

0

48

L

CAN- H

Input/Output

—

—

—

49

P

CAN- L

Input/Output

—

—

—

52

G/R

Rear window defogger
relay control signal

Input

ON

When rear window defogger switch
is ON.

0

When rear window defogger switch
is OFF.

Battery voltage

60

B/R

Ground (Signal)

—

ON

—

0
