DTC P1217 ENGINE OVER TEMPERATURE
EC-525
C
D
E
F
G
H
I
J
K
L
M
A
EC
CAUTION:
When a malfunction is indicated, be sure to replace the coolant. Refer to
. Also, replace the engine oil. Refer to
1.
Fill radiator with coolant up to specified level with a filling speed of 2 liters per minute. Be sure to
use coolant with the proper mixture ratio. Refer to
MA-11, "Anti-Freeze Coolant Mixture Ratio"
2.
After refilling coolant, run engine to ensure that no water-flow noise is emitted.
Overall Function Check
NBS000XE
Use this procedure to check the overall function of the cooling fan. During this check, a DTC might not be con-
firmed.
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pres-
sure fluid escaping from the radiator.
Wrap a thick cloth around cap. Carefully remove the cap by turning it a quarter turn to allow built-up
pressure to escape. Then turn the cap all the way off.
WITH CONSULT-II
1.
Check the coolant level in the reservoir tank and radiator.
Allow engine to cool before checking coolant level.
If the coolant level in the reservoir tank and/or radiator is below
the proper range, skip the following steps and go to
.
2.
Confirm whether customer filled the coolant or not. If customer
filled the coolant, skip the following steps and go to
.
3.
Turn ignition switch ON.
4.
Perform “COOLING FAN” in “ACTIVE TEST” mode with CON-
SULT-II.
5.
EC-529, "Diagnostic Procedure"
WITH GST
1.
Check the coolant level in the reservoir tank and radiator.
Allow engine to cool before checking coolant level.
If the coolant level in the reservoir tank and/or radiator is below
the proper range, skip the following steps and go to
.
2.
Confirm whether customer filled the coolant or not. If customer
filled the coolant, skip the following steps and go to
.
3.
Start engine.
CAUTION:
Be careful not to overheat engine.
4.
Turn air conditioner switch ON.
5.
Turn blower fan switch ON.
SEF621W
SEF646X
SEF621W
