NAVIGATION SYSTEM

AV-55

C

D

E

F

G

H

I

J

L

M

A

B

AV

Terminals and Reference Value for Display Unit

NKS002FU

72

(PU)

Ground

Communication signal
(

−

)

Input/

Output

ON

—

73

Ground

GPS signal

Input

ON

Connector is not connected.

Approx. 5 V

74

—

Shield

—

—

—

—

Terminal

(Wire color)

Item

Signal

Input/

output

Condition

Reference value

+

–

Ignition

switch

Operation

SKIA0176E

Terminal

 (Wire color)

Item

Signal

input/

output

Condition

Reference value

(+)

(–)

Ignition

switch

Operation

1

(B)

4

(G)

RGB signal (R: red)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

2

(W)

4

(G)

RGB signal (G: green)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

3

(R)

4

(G)

RGB signal (B: blue)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

4

(G)

Ground

RGB Ground

—

ON

—

Approx. 0 V

7

(P)

Ground

RGB synchronizing sig-
nal

Input

ON

—

8

(L)

Ground

RGB area (YS) signal

Input

ON

When inputting RGB image.

Approx. 5 V

12

—

Shield

—

—

—

—

SKIB2238J

SKIB2236J

SKIB2237J

SKIB3603E

AV-56

NAVIGATION SYSTEM

Terminals and Reference Value for NAVI Switch

NKS002FV

13

(B)

Ground

Communication signal
(

−

)

Input/

Output

ON

Press the  “BACK” switch.

14

(W)

Ground

Communication signal
(+)

Input/

Output

ON

Press the  “BACK” switch.

15

—

Shield

—

—

—

—

16

(G)

Ground

Communication signal
(

−

)

Input/

Output

ON

Press the  “BACK” switch.

19

(LG)

Ground

ACC power supply

Input

ACC

—

Battery voltage

20

(R)

Ground

Communication signal
(+)

Input/

Output

ON

Press the  “BACK” switch.

21

(Y)

Ground

Battery power supply

Input

OFF

—

Battery voltage

22

(B)

Ground

Ground

—

ON

—

Approx. 0 V

23

(Y)

Ground

Battery power supply

Input

OFF

—

Battery voltage

24

(B)

Ground

Ground

—

ON

—

Approx. 0 V

Terminal

 (Wire color)

Item

Signal

input/

output

Condition

Reference value

(+)

(–)

Ignition

switch

Operation

SKIA0176E

SKIA0175E

SKIA0176E

SKIA0175E

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

(+)

(–)

Ignition

switch

Operation

1

(LG)

Ground

ACC power supply

Input

ACC

—

Battery voltage

NAVIGATION SYSTEM

AV-57

C

D

E

F

G

H

I

J

L

M

A

B

AV

Terminals and Reference Value for Audio Unit for Base System

NKS002FW

Refer to

AV-21, "Terminals and Reference Value for Audio Unit for Base System"

 .

Terminals and Reference Value for Audio Unit for BOSE System

NKS002FX

Refer to

AV-22, "Terminals and Reference Value for Audio Unit for BOSE System"

 .

2

(R/L)

Ground

Illumination signal (+)

Input

OFF

Lighting switch position
1st or 2nd

Approx. 12 V

Lighting switch position
OFF

Approx. 0 V

3

(R/Y)

Ground

Illumination signal (–)

—

OFF

Illumination control switch
is operated by lighting
switch in ON position.

Change between 0 and 12 V

4

(R)

Ground

Communication signal
(+)

Input/

Output

ON

Press the  “BACK” switch.

5

(G)

Ground

Communication signal
(

−

)

Input/

Output

ON

Press the  “BACK” switch.

6

—

Shield

—

—

—

—

7

(B)

Ground

Ground

—

ON

—

Approx. 0 V

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

(+)

(–)

Ignition

switch

Operation

SKIA0175E

SKIA0176E

AV-58

NAVIGATION SYSTEM

Self-Diagnosis Function

NKS002FY

DESCRIPTION

●

Diagnosis function consists of the self-diagnosis mode performed automatically and the CONFIRMATION/
ADJUSTMENT mode operated manually.

●

Self-diagnosis mode checks for connections between the units constituting this system, analyzes each
individual unit at the same time, and displays the results on the LCD screen.

●

CONFIRMATION/ADJUSTMENT mode is used to perform trouble diagnoses that require operation and
judgment by an operator (malfunction that cannot be automatically judged by the system), to check/
change the set value, and to display the History of Errors of the navigation system.

DIAGNOSIS ITEM

Mode

Description

Self Diagnosis

●

NAVI control unit diagnosis and connection diagnosis between NAVI
control unit and each unit

●

The DVD-ROM drive diagnosis of NAVI control unit and the connec-
tion diagnosis between NAVI control unit and GPS antenna can be
performed
(DVD-ROM drive will not be diagnosed when no map DVD-ROM is in
it.)

Confirmation/
Adjustment

Display Diagnosis

The tint can be confirmed by the color spectrum bar display. The shad-
ing of color can be confirmed by the gradation bar display.

Vehicle Signals

Diagnosis of signals can be performed for vehicle speed,  lights, ignition
switch, and reverse.

Navigation

Steering Angle
Adjustment

When there is a difference between the actual turning angle and the
vehicle mark turning angle, it can be adjusted.

Speed Calibration

When there is a difference between the current-location mark and the
actual location, it can be adjusted.

Error History

The system malfunction and the frequency when occurred in the past
are displayed. When the malfunctioning item is selected, the time and
place that the selected malfunction last occurred are displayed.

Delete Unit Connection Log

Erase the connection history of unit and error history
