DLN-190 < DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: R200] DRIVE PINION 2WD : Disassembly INFOID:0000000003135842 1. Remove differential case assembly. Refer to 2. Remove drive pinion lock nut with the flange wrench. 3. Put matching mark (B) on the end of drive pinion. The matching CAUTION: For matching mark, use paint. Never damage companion 4. Remove companion flange using the suitable pullers. 5. Press drive pinion assembly out of gear carrier. CAUTION: Never drop drive pinion assembly. 6. Remove front oil seal. 7. Remove side oil seal. 8. Remove pinion front bearing inner race. 9. Remove collapsible spacer. JSDIA0033ZZ JSDIA0016ZZ JSDIA0034ZZ PDIA0760J |
