Fig. 98: Defining Gear Tooth Nomenclature The side of the ring gear tooth which curves outward or is convex, is the drive side (4). The Adjustments Affecting Tooth Contact The following 2 adjustments affect the tooth contact pattern: Backlash adjustment Pinion depth adjustment
2007 Hummer H3 2007 Driveline/Axle Front Drive Axle - H3
|
